300KW Medium Frequency Induction Heating Machine For Forging
300KW Medium Frequency Induction Heating Machine For Forging
Advantages of Medium Frequency Induction Hot Forging Heating Machine:
1. Heating fast and uniform.
2. Machine power can be adjust stable.
3. Easy installation, simple operation.
4. Safe and reliable. No high voltage, very safe for operating people.
Technical parameters of induction forging machine:
|
Item Model |
ZP-300 |
| Rated Voltage(V) |
380V/50Hz |
| Input Power(kVA) |
5~200 |
| Input Oscillation Frequency(kHz) |
3~19 |
| Load Duration |
100% |
| Cooling Water Pressure(Mpa) |
0.25~0.4 |
| Output Water Flow(L/Min) |
35~50 |
Applications of Iinduction hot forging heating machine:
1. Hot forging aims to fabricate the work pieces of certain temperature (different materials require different temperatures) into other shapes through forging press with the help of punch press, forging machine or other equipments. for instances, hot extrusion of watch case, watch flan, handle, mold accessory, kitchen and table ware, art ware, standard part, fastener, fabricated mechanical part, bronze lock, rivet, steel pin and pin.
2. Hot fitting refers to the connection of different metals or metals with nonmetals through the heating based on the principle of hot expansion or hot smelting, for instances, embedded welding of copper core of computer radiator with aluminum sheet and speaker web, compound of steel and plastic tube, sealing of aluminum foil (tooth paste peel), motor rotor and sealing of tubular electric heating element.
Packaging & Shipping:
1. On the outside, packing fumigation wooden cases for induction heating machine.
2. Inside part, packing plastic film, in case of the friction of the induction heating machine.
3. Induction coil is packaged inside.
4. The induction heating machine can be transported by ship air or train.
