3000lbs Astm A105 Socket Weld Tees High Pressure
Price:
0.16-0.86 usd/piece
MOQ:
50piece
Delivery Time:
7 work days
Brand:
QD
Product Description
3000lbs ASTM A105 High Pressure Socket Weld Forged Tee Carbon Steel Forged Pipe Fittings
Specifications:
Nominal Diameter |
Depth of Socket |
Dimension of Socket |
Wall Thicknes | Center to Bottom of Socket | ||||||
| Cmin | Lateral |
|||||||||
| A | H | |||||||||
| DN | NPS | Jmin | d1 | 3000LB | 6000LB | 9000LB | 3000LB | 6000LB | 3000LB | 6000LB |
| Sch80 | Sch160 | XXS | Sch80 | Sch160 | Sch80 | Sch160 | ||||
| 6 | 1/8 | 10 | 10.7 | 3.2 | 3.5 | - | - | - | - | - |
| 8 | 1/4 | 10 | 14.1 | 3.3 | 4.0 | - | 32 | - | 8 | - |
| 10 | 3/8 | 10 | 17.5 | 3.5 | 4.4 | - | 37 | - | 8 | - |
| 15 | 1/2 | 10 | 21.8 | 4.1 | 5.2 | 8.2 | 41 | 51 | 11 | 13 |
| 20 | 3/4 | 13 | 27.4 | 4.3 | 6.1 | 8.6 | 51 | 60 | 13 | 14 |
| 25 | 1 | 13 | 34.2 | 5.0 | 7.0 | 10.0 | 60 | 71 | 14 | 18 |
| 32 | 1.1/4 | 13 | 42.9 | 5.3 | 7.0 | 10.6 | 71 | 81 | 18 | 21 |
| 40 | 1.1/2 | 13 | 48.3 | 5.6 | 7.8 | 11.2 | 81 | 98 | 21 | 25 |
| 50 | 2 | 13 | 61.1 | 6.1 | 9.5 | 12.2 | 98 | 120 | 25 | 29 |
| 65 | 2.1/2 | 16 | 76.9(73.8) | 7.7 | 12.5 | - | - | - | - | - |
| 80 | 3 | 16 | 89.8 | 8.3 | 13.8 | - | - | - | - | - |
| 100 | 4 | 19 | 115.5 | 9.4 | - | - | - | - | - | - |
FAQ:
Q1: How to order?
1. To specity standard and the thickness.
2. To specity surface treatment.
3. To specity figure size and quantity.
Q2: After sales service?
Quality are promised.We have a dedicated after-sales department to be responsible for all subsequent work after delivery.
Q3: Can I have a sample order for pipe fittings?
Yes, we welcome sample order to test and check quality.Mixed samples are acceptable.
Q4: Do you offer guarantee for the products?
Yes, we offer almost 20 years warranty to our products.
