ASTM TP 304 Inox Stainless Steel Pipe Tube 309S 310S 316ti 321 347H 2507
ASTM TP 304 Inox Stainless Steel Pipe Tube 309S 310S 316ti 321 347H 2507
GENERAL PROPERTIES
Austenitic stainless steels are amongst the most widely used classes of metals. Primarily, many austenitic alloys such as Stainless Steel 316Ti Seamless Pipe are preferred over carbon steels for several reasons. The principal reason for their use is corrosion resistance. For a piping system to survive in environments, corrosion resistance is an integral property. With corrosion resistance higher than grade 304, the ASTM A312 TP 316TI pipe delivers excellent performance
Specification
| Specifications | ASTM A213 and ASME SA213 |
| Dimensions | ASTM, API and ASME |
| Size in Inch | 1/8 TO 30 |
| Specialized in | Large Diameter Size Supplier |
| Type | Fabricated, Seamless, ERW, Welded, LSAW Supplier and Manufacturer |
| Length | Single Random/ Double Random/ Cut Length |
| Form | Square/ Rectangular/ Round/ Hydraulic |
| Schedule | Schedule 30, Schedule 160, Schedule 120, Schedule 80, Schedule 20, XXS, XS, Schedule 40, Schedule 140, Schedule 80, Schedule 60, STD Supplier and Manufacture |
| End | Plain/ Treaded/ Beveled |
| Pipe Marking | All Pipes are marked as follows: Supplier or Manufacturer’s Name, Grade, OD, Standard, Thickness, Length, Heat No. |
|---|
ASME SA 312 Tp316Ti Welded Pipe Tolerance
| Outer Diameter in MM | Tolerance in MM |
|---|---|
| 35 to 38 | +/- 0.15 |
| 4 to 35 | +/- 0.08 |
| 60 and above | +/- 0.25 |
| 38 to 60 | +/- 0.20 |
ASTM A312 TP 316TI pipe Chemical Formula
| Grade | Carbon | Manganese | Silicon | Phosphorous | Sulfur | Chromium | Molybdenum | Nickel | Nitrogen | |
|---|---|---|---|---|---|---|---|---|---|---|
| 316Ti Stainless Steel | Minimum | – | – | – | – | – | 16.0 | 2.00 | 10.0 | – |
| Maximum | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 3.00 | 14.0 | – | |
SS UNS S31703 Welded Pipe Mechanical Characteristics
| Grade | Tensile Strength Minimum | Yield Strength Minimum | Elongation Minimum | Hardness | |
| Rockwell B Maximum | Brinell Maximum | ||||
| 316Ti Stainless Steel | 515 | 205 | 35 | 75 | 205 |
316ti Stainless Steel Efw Tubing Physical Properties
| Grade | Density | Elastic Modulus | Mean Coeff. of Thermal Expansion | Thermal Conductivity | Specific Heat 0 To 1000C | Electrical Resistivity | |||
|---|---|---|---|---|---|---|---|---|---|
| 0 To 1000 C | 0 To 3150 C | 0 To 5380 C | at 1000 C | at 5000 C | |||||
| 316L | 8000 | 193 | 15.9 | 16.2 | 17.5 | 16.3 | 21.5 | 500 | 740 |
Why Choose Us?
1. who are we?
We are based in Wuxi, China, start from 2019,sell to Domestic Market and Abroad Market. There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
3.what can you buy from us?
stainless steel plate,stainless steel coil,stainless steel sheet,stainless steel pipe and tube,sainless steel bar
4. why should you buy from us not from other suppliers?
Runs perennial exports of quality assured steel mills ,including Shanxi TISCO, Baosteel, Shanghai Krupp, Ningbo Baoxin, Guangzhou Lianzhong, Zhangjiagang Pohang, Qingdao Pohang, Sweden AvestaPolarit, Finland OUTKUMPU, Spain Acerinox, South Africa Columbus
