ASTM A653 En10327 10326 Galvanized Steel Coils Z30-275 Z60 Dx51d
Manufactures Price ASTM A653 En10327 10326 Hdgi Galvalume Gi Secc Zinc Coated Z30-275 Z60 Dx51d Sg550 Hot Dipped Galvanives steel coil
Galvanized steel coil, immersing the thin steel plate in the molten zinc bath, and adhering a layer of zinc thin steel plate on the surface. It is mainly produced by the continuous galvanizing process, that is, the coiled steel plate is continuously immersed in the zinc-melted plating tank to make galvanized steel plate; alloyed galvanized steel plate. This kind of steel plate is also made by the hot-dip method, but it is heated to about 500 °C immediately after exiting the tank to form an alloy film of zinc and iron. This galvanized steel coil has good paint adhesion and weldability.
| PRODUCT NAME | ASTM A653 En10327 10326 Galvanized Steel Coils Z30-275 Z60 Dx51d |
| STANDARD | EN10346, JIS G3302, ASTM A653,AS 1397,GB/T 2518 |
| STEEL GRADE | DX51D, DX52D, DX53D, DX54D,DX55D,DX56D,DX57D, S220GD, S250GD, |
| S280GD, S320GD,S350GD, S390GD,S420GD,S450GD,,S550GD, SGHC, | |
| SGH340, SGH400, SGH440, SGH490,SGH540, SGCC,SGCH,SGCD1, | |
| SGCD2, SGCD3, SGCD4,SGC340, SGC400 , SGC440, SGC490,SGC570; | |
| CS-A,CS-B,CS-C,GRADE 33,GRADE 37.GRADE 40,GARDE 50, | |
| GRADE60,GRADE70,GRADE80G1,G2,G3,G250,G300,G450,G550 AS REQUIREMENT | |
| TYPE | COIL/SHEET/PLATE/STRIP |
| THICKNESS | 0.12MM-6.0MM OR 0.8MM/1.0MM/1.2MM/1.5MM/2.0MM |
| WIDTH | 600MM-1800MM OR 914MM/1000MM/1200MM/1219MM/1220MM/1524MM |
| ZINC COATING | Z30G/M2-Z600G/M2 |
| SPANGLE TYPE | ZERO SPANGLE , SMALL SPANGLE , REGULAR SPANGLE |
| SURFACE STRUCTURE | OILED (O),PASSIVATED(C),PASSIVATED AND OILED (CO) |
| ,SEALED (S),PHOSPHATE (P),PHOAPHTE AND OILED (CO) | |
| COIL WEIGHT | 3 TONS -8TONS |
| COIL ID | 508MM/610MM |
Our advantage:
Whether you need structural steel, complex miscellaneous metals, or stock steel material you will get:
1. The Right Material, First Time: Quality is the hallmark of our reputation.
2.On Time Delivery: Your projects stay on schedule.
3.Ongoing Communication: Everyone is fanatically responsive to your needs. We handle the project so there are no surprises for you.
4.ISO and SGS Certification: We help you meet your goals plus the goals of your owners/customers.
