1.5mm Thickness 316L 317 Stainless Steel Coils Plate High Cryogenic Strength
1.5mm Thickness 316L 317 Stainless Steel Coils Plate High Cryogenic Strength
Stainless Steel S317L Coils containing increased resistivity for resisting different types of chemical attacks, it possesses excellent strength properties which make him capable of utilized at elevated temperature. The chemical mixture with additional content of molybdenum element give Stainless Steel 317L Coils stability in service, it serves characteristics like excellent magnetic properties, cryogenic strength, ductility and many more. It has crevice corrosion-resistant, lesser inter-granular precipitation and rupture, higher creep strength. Stainless Steel 317L Coils are commonly used for applications in flue gas desulfurization systems, condenser, petrochemical, and many more. These are highly durable, and robust products can withstand under the high temperature.
Stainless Steel 317L Coils Specification
Specifications : ASTM A240 / ASME SA240
Size : 1/4" to 4"
Range : 5mm To 150mm
Thickness : 4.0mm - 100mm
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange)
SS 317L Coils Equivalent Grades
| Grade | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
SS 317L Coils Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 - 20.00 | rowspan="2">3.00 - 4.00 | 11.00 - 15.00 | 57.89 min |
SS 317L Coils Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Why Choose Us?
1. who are we?
We are based in Wuxi, China, start from 2019,sell to Domestic Market and Abroad Market. There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
3.what can you buy from us?
stainless steel plate,stainless steel coil,stainless steel sheet,stainless steel pipe and tube,sainless steel bar
4. why should you buy from us not from other suppliers?
Runs perennial exports of quality assured steel mills ,including Shanxi TISCO, Baosteel, Shanghai Krupp, Ningbo Baoxin, Guangzhou Lianzhong, Zhangjiagang Pohang, Qingdao Pohang, Sweden AvestaPolarit, Finland OUTKUMPU, Spain Acerinox, South Africa Columbus
