High Strength Black Iron Q355B Q235 A106 Carbon Weleded Steel Pipe With Stock
High Strength Black Iron Q355B Q235 A106 Carbon Weleded Steel Pipe With Stock
Q235 steel is equivalent to Japenese steel grade SS400 in application, the only difference is that ss400 steel requires only S,P composition < 0.050, Q235 has requirements for More element C, Si, Mn, S, P. Yield strength of q235 is >235Mpa, which is almost the same to SS400 245Mpa. Q represents the yield of this material, the latter 235, refers to the yield value of this material, at about 235MPA. With the increase of the thickness of steel plate, the yield value decreases. It is widely used in construction and engineering structures.
Product Description:
| Type | Seamless carbon steel pipe / Line Pipe | |
| Materials | API 5L /A53 /A106 GRADE B and other material which client inquired | |
| Size | Outer Diameter | Seamless:17-914mm 3/8"-36" |
| Wall Thickness | SCH10 SCH20 SCH30 STD SCH40 SCH60 XS SCH80 SCH100 SCH120 SCH140 SCH160 XXS |
|
| Length | Single random length/Double random length 5m-14m,5.8m,6m,10m-12m,12m or as customer's actual request |
|
| Ends | Plain end/Beveled,protected by plastic caps on both ends, cut quare,grooved,threaded and coupling,etc. | |
| Surface Treatment | Bare,Painting black,varnished,galvanized,anti-corrosion 3PE PP/EP/FBE coating | |
| Technical Methods | Hot-rolled/Cold-drawn/Hot-expanded | |
| Testing Methods | Pressure test,Flaw detection,Eddy current testing, Hydro static testing or Ultrasonic examination and also with chemical and physical property inspection |
|
| Packaging | Small pipes in bundles with strong steel strips,large pieces in loose; Covered with plastic woven bags; Wooden cases;Suitable for lifting operation;Loaded in 20ft 40ft or 45ft container or in bulk;Also according to customer's requests |
|
| Origin | China | |
| Application | Conveying oil gas and water | |
| Third Party Inspection | SGS BV MTC | |
| Trade Terms | FOB CIF CFR | |
| Payment Terms | FOB 30%T/T,70% before shipment CIF 30% pre-payment and the balance to be paid before making shipment or Irrevocable 100% L/C at sight |
|
Meaning and Designation
“Q” is the first letter of Chinese spelling of “Qu Fu Dian”, which means Yield Point.
“235” refers to the minimum yield strength 235 MPa tested with steel diameter ≤ 16mm.
Features of Q235B Pipe
- Good plasticity & toughness
- Good weldability
- Great cold bending performance
Q235B Pipe Chemical Composition
| C | Si | Mn | P | S |
|---|---|---|---|---|
| 0.2 | 0.35 | 1.4 | 0.045 | 0.045 |
Q235B Pipe Mechanical Properties
| Tensile Strength | Yield Strength | Elongation |
|---|---|---|
| 370-500 MPa | 235 MPa | 25% |
Q235B Pipe Equivalent Grade
| Equivalent Grade | US | Germany | UK | Japan |
|---|---|---|---|---|
| Q235B | ASTM A36, ASTM A283 | DIN EN 10025-2 | BS EN 10025-2 | JIS G3101, G3106 |
Supply Range of Carbon Steel Pipes
Material: ASTM, DIN, JIS, GB, EN
Sizes: 1/2” to 48”
Thickness: Schedule 5S – Schedule XXS
Coatings for 10″ Q235B Steel Pipe: 3PE, Galvanized, As custimer requests
Q235 Steel Equivalent Standard
| China | USA | Germany | Japanese | France | UK | ISO |
|---|---|---|---|---|---|---|
| GB | ASTM | DIN | JIS | NF | BS | ISO |
| Q235A Steel | Gr.D (σS230MPa) |
Ust37-2 RSt37-2 |
SS440 SM400A (σS245MPa) |
080A15 (σS235MPa) | E235B (σS235MPa) | |
| Q235B Steel | Gr.D (σS230MPa) |
S235JR S235JRG1 S235JRG2 (σS235MPa) |
SS440 SM400A (σS245MPa) |
S235JR S235JRG1 S235JRG2 (σS185MPa) |
080A15 S235JR S235JRG1 S235JRG2 (σS185MPa) |
E235B (σS235MPa) |
| Q235C Steel | Gr.D (σS230MPa) Gr.65 (σS240MPa) |
S235JO (σS235MPa) | SM400A SM400B (σS245MPa) |
S235JO (σS235MPa) | 080A15 S235JO (σS235MPa) |
E235C (σS235MPa) |
| Q235D Steel | Gr.D (σS230MPa) |
S235J2G3 S235J2G4 (σS235MPa) |
SM400A (σS245MPa) | S235J2G3 S235J2G4 (σS235MPa) |
S235J2G3 S235J2G4 (σS235MPa) |
E235D (σS235MPa) |
Payment Terms
1.Payment: T/T, L/C, Western Union, MoneyGram,PayPal; 30% deposits; 70% balance before delivery.
2.MOQ: 1pcs
3.Warranty : 3 years
4.Package Informations: 1) EXPORT, In 20 feet (GW 25 ton) or 40 feet Container (GW 25 ton)
2)as customer's requirement
Why choose us?
(1) The leading exporter in China special steel industry.
(2) Large stocks for various sizes, fast delivery date.
(3) Good business relationship with China famous factories.
(4) More than 7 years steel exporting experience.
(5) Good after-sales service guarantee.
