Hot Rolled Stainless Steel Plate Coil 5mm Chromium Nickel SS 201 202 304
Hot Rolled Stainless Steel Plate Coil 5mm Chromium Nickel SS 201 202 304
- Austenitic. Type 304 is the most versatile and frequently used chromium nickel stainless steel. It is an all-purpose alloy with a multitude of benefits. It has good corrosion and oxidation resistance, performs well in terms of formability and weldability and is easy to clean. Because this material offers a superb combination of high strength and light weight, about half of the stainless produced in the United States is type 304.
- Used in a variety of applications: Some of the typical uses of grade 304 include appliances, cladding, consumer and industrial products, flanges and valves, handrails, hardware and fasteners, HVAC, kitchen, food and beverage equipment, medical equipment, oil and gas parts, pipes and tubes, plumbing supplies, storage tanks and window frames.
- Able to be processed in many ways: Metal processors and fabricators stamp, form, draw, bend, cut and weld alloy 304 to produce various parts. Cold working will increase strength and hardness.
|
Product Name |
stainless steel coil |
|
Width |
500mm,1000mm,1219mm(4feet),1250mm,1500mm,1524mm(5feet), |
|
Length |
2000mm,1219mm(4feet),1250mm,1500mm,1524mm(5feet), |
|
Mill |
TISCO, LISCO, BAO STEEL, etc. |
|
Surface |
Common: 2B, 2D, HL(Hairline), BA(Bright annealed), No.4 |
|
Standard |
GB,AISI,ASTM,DIN,EN,SUS,UNS ,etc. |
|
Grade |
200,300,400 series |
|
Technique |
Hot Rolled, Cold Rolled, Cold Drawn, Forged |
|
Tolerance |
H8,H9 or as required |
|
MOQ |
1 ton |
|
Port |
Shanghai or any port of China |
|
Certification |
ISO,SGS |
|
Lead Time |
7-15 working days after the receipt of 30% deposit |
|
Payment Terms |
30% TT for deposit,70% TT /70% LC with the copy of B/L within 3 working days |
|
Price Terms |
FOB, CIF, CFR |
|
Packing |
Wooden Pallet or according to customer's requirements |
|
Surface
|
Characteristic
|
Processing Technology
|
|
N0.1
|
Original
|
Pickled after hot rolling
|
|
2D
|
Blunt
|
Hot rolling + annealing shot peening pickling + cold rolling + annealing pickling
|
|
2B
|
Blurred
|
Hot rolling + annealing shot peening pickling + cold rolling + annealing pickling + tempering rolling
|
|
N0.3
|
Matte
|
Polishing and tempering rolling with 100-120 mesh abrasive materials
|
|
N0.4
|
Matte
|
Polishing and tempering rolling with 150-180 mesh abrasive material
|
|
NO.240
|
Matte
|
Polishing and tempering rolling with 240 mesh abrasive materials
|
|
NO.320
|
Matte
|
Polishing and tempering rolling with 320 mesh abrasive materials
|
|
NO.400
|
Matte
|
Polishing and tempering rolling with 400 mesh abrasive materials
|
|
HL
|
Brushed
|
Grind the surface of the steel belt with an appropriate grinding grain size to make it show a certain longitudinal texture
|
|
BA
|
Bright
|
The surface is annealed and shows high reflectivity
|
|
6K
|
Mirror
|
Rough grinding and polishing
|
|
8K
|
Mirror
|
Fine grinding and polishing
|
| Type 304 | Type 304L | Type 304H | |
|---|---|---|---|
| ASTM A240/A240M (UNS Designation) | S30400 | S30403 | S30409 |
| Chemical Composition | |||
| Chromium | 18.0-20.0% | 18.0-20.0% | 18.0-20.0% |
| Nickel | 8.0-11.0% | 8.0-12.0% | 8.0-10.5% |
| Carbon (max.) | 0.080% | 0.030% | .040-.100% |
| Manganese (max.) | 2.000% | 2.000% | 2.000% |
| Silicon (max.) | 0.750% | 0.750% | 0.750% |
| Sulfur (max.) | 0.030% | 0.030% | 0.030% |
| Phosphorus (max.) | 0.045% | 0.045% | 0.045% |
| Nitrogen (max.) | 0.100% | 0.100% | |
| Mechanical Properties (annealed) | |||
| Tensile (min. psi) | 75,000 | 70,000 | 75,000 |
| Yield (min. psi) | 30,000 | 25,000 | 30,000 |
| Elongation (in 2″, min %) | 40 | 40 | 40 |
| Hardness (max Rb) | 92 | 92 | 92 |
|
Tensile strength (Mpa) |
Yield Strength (Mpa) |
Elongation (%) |
Hardness (HR) |
|
|
304 |
≥515 |
≥205 |
≥40 |
≥92 |
|
304L |
≥485 |
≥170 |
≥40 |
≥92 |
|
304H |
≥515 |
≥205 |
≥40 |
≥92 |
|
Main Chemical composition of 304/304L/304H |
|||||||
|
C(%) |
Si(%) |
Mn(%) |
P(%) |
S(%) |
Cr(%) |
Ni(%) |
|
|
SUS304L |
≤0.03 |
≤0.75 |
≤2.00 |
0≤.045 |
≤0.03 |
18-20 |
8-12 |
|
SUS304H |
0.04-1.0 |
≤0.75 |
≤2.00 |
0.≤045 |
≤0.03 |
18-20 |
8-10.5 |
|
Physical Properties |
||||||||
|
Density (kg/m3) |
Elastic Modulus (GPa) |
Specific Heat 0-100 °C (J/kg.K) |
Electrical Resistivity (nΩ.m) |
Mean Coefficient of Thermal Expansion (μm/m/°C) |
Thermal Conductivity (W/m.K) |
|||
|
0-100 °C |
0-315 °C |
0-538 °C |
at 100 °C |
at 500 °C |
||||
|
8000 |
193 |
500 |
720 |
17.2 |
17.8 |
18.4 |
16.2 |
21.5 |
|
Specifications for 304 304L 304H stainless steel |
||||
|
Technical |
Thickness |
Width |
Finish |
Origin |
|
Cold rolled |
0.5mm-6.0mm |
Standard size in China:1000mm 1219mm 1500mm or as required |
2B / No.4 /HL / BA / Mirror etc |
TISCO / ZPSS / JISCO / Baosteel etc |
|
Hot rolled |
3.0mm-80.0mm |
Standard width in China: 1219mm 1500mm 180mm 2000mm or as required |
No.1 |
TISCO / ZPSS / Baosteel / JISCO etc |
