Hot Rolled 4x8 High Strength Steel Plate 700mc Anti Abrasion EH400 EH500
Bimetal composite wear-resisting steel plate is composed of low carbon steel plate and alloy wear-resisting layer, and the anti-wear layer generally accounts for 1/3-1/2 of the total thickness. When working, the matrix provides comprehensive properties such as strength, toughness and plasticity to resist external forces, and the wear-resisting layer provides wear-resisting properties to meet the requirements of specified working conditions.
Wear-resisting steel plate alloy wear-resisting layer and matrix is metallurgical bonding. Through special equipment, using automatic welding process, the high hardness self-protection alloy welding wire evenly on the base material. The number of composite layers is from one layer to two layers and even several layers. In the composite process, uniform transverse cracks appear because of the different alloy shrinkage ratio, which is a significant feature of wear-resisting steel plate.
Wear resistant layer is mainly chromium alloy, but also add manganese, molybdenum, niobium, nickel and other alloy components, the microstructure of carbide fiber distribution, fiber direction and surface perpendicular. The microhardness of carbide can reach above HV1700-2000, and the surface hardness can reach HRC 58-62. Alloy carbide has strong stability at high temperature, maintain high hardness, but also has good oxidation resistance, within 500℃ completely normal use.
Good wear-resistant steel with high abrasion resistance and impact performance is good, can be cutting, bending, welding, etc., can adopt welding, plug welding, bolt connection way to connect with other structures, such as the scene of the maintenance process possesses the characteristics of time saving, convenient and widely used in metallurgy, coal, cement, power, glass, mining, building materials, brick and tile industry, compared with other materials, With high cost performance, it has been favored by more and more industries and manufacturers.

Product Description​


Wear-resistant steel plate WNM360/500/400
Application: Wear-resistant steel is widely used in mining machinery, coal lumbering, engineering machinery, agricultural machinery, building materials, electric machinery, railway transportation departments.
Quick Details:
Standard: WJY030-2010
Grade: NM360/500/400
Place of Origin: China (Mainland)
Brand Name: Wu Gang
Type: Steel plate Surface treatment: Hot rolled
Specifications:
Steel Plate NM360/400/500
1 Grade: NM360/400/500
2 T: 6-700mm; Length: 3000-12000mm; W: 1500-4000mm;
3 Delivery time: Average Period in 30 days



Detailed Photos




FAQ

Can you send products to my country?
Sure, we can. If you do not have your own ship forwarder, we can help you.
Will you delivery the goods on time?
Yes,we promise to provide best quality products and delivery on time no matter if the price change lot or not.Honesty is our company's tenet.
How can I get a quotation from you ?
You can leave us message, and we will reply every message in time. Or we may talk on line by Trademanager.
And you can also find our contact information on contact page.
How do you make our business long-term and good relationship?
1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them
Please contact me for more info today!
