Multi Power CCT Adjustable LED Stairwell Lights 130 M/W
4” Wide 2FT Multi Power And CCT Adjustable 1300-4000lm LED Linear Stairwell 30-50K With Emergency Pack
- Integral with new trend of field-adjustable functions provide our customers greater flexibility on wattages and color temperatures.
-
Optional Occupancy Sensor & Built-in Emergency Backup
-
Ideal for stairwell, passageway and general lighting etc.
- UP TO 135LM/W
- An auxiliary to connect low voltage sensor/BLE or other IOT network.
- Various Lens Option: Clear, Frosted,
- Built-in Emergency Driver Option.
- L70>50,000hrs, 5 year warranty.
| Model No | DLC | Input Voltage | Wattage | Lens | CRI/CCT | Rated Lumen @ 50K |
Rated Efficancy @ 50K |
Viewing Angle | Replacing |
| N-LC4-2FT-30W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC
|
30 |
Frosted/ Clear
|
Ra>80, 30K 35K 40K 50K |
3700 | 123 | 180° |
3 X T5HO 2FT 24W 4 X T8 2FT 17W |
| N-LC4-2FT-20W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC |
20 |
Frosted/ Clear |
Ra>80, 30K 35K 40K 50K |
2440 | 127 | 180° |
3 X T5HO 2FT 24W 4 X T8 2FT 17W |
| N-LC4-2FT-14W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC |
14 |
Frosted/ Clear |
Ra>80, 30K 35K 40K 50K |
1750 | 128 | 180° |
3 X T5HO 2FT 24W 4 X T8 2FT 17W |
| N-LC4-2FT-10W-1XX- [Blank, S1, S2]-C-FL- CT-FA-Z |
YES |
100-277VAC or 100-347VAC |
10 |
Frosted/ Clear |
Ra>80, 30K 35K 40K 50K |
1250 | 127 | 180° |
1 X T5HO 2FT 24W 1 X T8 2FT 17W |
4W or 8W UL Listed Emergency Backup
- Listed for field Instllation-UL924 & CSA C22.2 NO. 141
- Input: 120-277VAC/347VAC 50/60Hz
- Output: 25-50VDC, 15 or 30W
- Illumination Time: 90min
- Battery Type:Li-ion/Ni-MH
- Battery Recharge Time: 24Hrs
- Surge Protection: 3KV
- Protection:
- Input over-current Protection (Fuse)
- Output over-voltage Protection
- Output Low Voltage Protection
- Output Short Circuit Protection
- Working Temp.: 10℃ to 50℃
HOW TO CHANGE THE WATTAGE IN THIS FIXTURE
|
Power Adjustable Slide Switch Position |
||||
|
Size/Positon |
W1 |
W2 |
W3 |
W4 |
|
2FT |
30W |
20W |
14W |
10W |
|
4FT |
40W |
25W |
18W |
12W |
|
CCT Tunable Slide Switch Position |
|
|
Position/Group |
CCT |
|
CCT1 |
3000K |
|
CCT2 |
3500K |
|
CCT3 |
4000K |
|
CCT4 |
5000K |
Stairwell Lighting, Passageway Lighting, Corridor Lighting, Shop Lighting, Strip Lighting, Low Bay Lighting, Warehouse Lighting
