T51 Rock Drilling Tools 30kW YDH 300 Down The Hole Maximum Aperture 115mm
Price:
Price negotiations
MOQ:
1PCS
Delivery Time:
20 work days
Brand:
YDH
Product Description
Rock Drilling Tools YDH 300 hydraulic rock drill Driving hole, pipe shed hole, medium deep hole
Product feature of Rock Drilling Tools
YHD300 is used for driving hole, pipe shed hole and medium deep hole.
Suitable for T51 drilling tools.
Effective aperture 76mm or maximum aperture 115mm.
Product data of Rock Drilling Tools
| Technical data | ||
| Percussion Oil Pressure | bar | 175 |
| Percussion Oil Flow | l/min | 140 |
| Rotation Oil Pressure | bar | 150 |
| Rotation Oil Flow | l/min | 40 - 50 |
| Rotation torque(max) | Nm | 830 |
| Rotation speed(max) | rpm | 250 |
| Percussion frequency | min | 2500-3700 |
| Percussion energy | J | 450 |
| Output energy | kW | 30 |
| Drilling diameter | mm | 43 - 115 |
| Weight | kg | 230 |
