High Compression Honda Sealed Power Pistons Fit HT110 CLY DIA 52.4mm
52.4mm CLY DIA Honda Motorcycle Pistons Motor Engine Parts HT110
Specification
|
Brand Name
|
LIDON
|
| Place of Origin |
Guangzhou, China
|
| Product name | Motorcycle HT110 Piston Kit |
| Quality | A class |
| Material | Aluminum Alloy |
| Color | As picture show |
| Application | Motorcycle Engine System |
| weight |
95g
|
| Packing | Boxes+ Carton |
| CYL DIA | 52.4mm |
| Pin Size | 13*41mm |
| Shipment | Sea, Air, Express |
Description
Piston kits are included piston, piston pin and piston rings.
The piston diameter: 52.4mm
The piston pin diameter: 13mm
The length of piston pin: 41mm
The piston ring diameter: 52.4*1.0*1.0*2.0mm
Made of high-quality materials,more durable and wear-resistant
It has good thermal conductivity,high temperature resistance,high pressure,corrosion,sufficient heat dissipation capacity,and small heating area
Excellent quality, fast delivery, simple after-sales. We make every effort to provide customers with satisfactory service
Product Features
The functions of piston are :
A piston is a component of engines, reciprocating pumps, compressors and cylinders, among other similar mechanisms. The moving piston is contained by a cylinder and made gas-tight by piston rings. In an engine, piston transfers force from expanding gas in the cylinder to the crankshaft via a piston rod and/or connecting rod.
Advantage :
High performance piston, extended life and sustained power, CNC machined fully-polished finish looks great and available in a best reasonable price.
Product Model
| Model Name | Weight(g) | CLY DIA(mm) |
| HONDA JH70 | 65 | 47 |
| HONDA CD70 | 64 | 47 |
| HONDA CG125/VS125 | 118 | 56.5 |
| HONDA CG150/KG9 | 143 | 62 |
| HONDA CC200/KBB | 135 | 63.5 |
| HONDA CG200-A | 156 | 63.5 |
| HONDA CG250 | 140 | 67 |
| HONDA JD100/GN5 | 78 | 50 |
