120V SPD Signal Surge Protection Device Large Discharge Current
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
8 days
Brand:
HAMMOND
Product Description
Large Discharge Current Long Service Life Signal Surge Protector
HDX-RJ11 series audio SPD for Modem, DTU, DDN special line, fax, telephone over-voltage protector signal, designed to prevent induced over-voltage due to ground potential rise or lines and cause harm to the equipment.The product adopts RJ11 interface, easy to use and easy to install.The protection circuit is composed of multi-level protection elements, which have the characteristics of large discharge current, low clamping power and long service life.
| MODEL |
HDX-RJ11/AD110
|
HDX-RJ11-48
|
HDX-RJ11-120 |
| Rated working voltage |
|
48V
|
120V |
| Maximum continuous running voltage. | 150V | 60V | 150V |
| Rated working current In. | 300MA | ||
| SPD test category | C2 | ||
| Nominal discharge current Isc (8/20) : symmetric/asymmetric (PE) | 100A/1KA | 100A/1KA | |
| Voltage protection level Up: symmetric/asymmetric (PE) | 240V/0.5KV | 96V/0.5KV | |
| Working frequency | <=10MHZ | <=10MHZ | |
| Insertion loss | 0.5DB | 0.5DB | |
| Overall dimensions | 108mm*25.4mm*25.4mm | 108mm*25.4mm*25.4mm |
|
|
The interface type |
RJ11 |
| Working conditions | Temperature range:-40.C~+70.C |
| Moderate range:30%~85%(25.C) |
