Auto Wheel Hub Tapered Roller Bearing 3579/25 Chrome Steel GCr15
Auto Wheel Hub Tapered Roller Bearing 3579/25 Bearing Chrome Steel GCr15
Tapered Roller Bearing Specification
Bore Size: 0 - 42.78 mm
Outside Diameter: 0 - 87.28 mm
Model Number: 3579/3525
Description: Taper Roller Bearing
Width: 30.162mm
Material: GCr15,Carbon steel
Taper Roller Bearing Description
Tapered roller bearings consist of four basic components including: the cone (inner ring), the cup (outer ring), tapered rollers, and a cage (roller retainer). The cone, cup and rollers carry the load while the cage spaces and retains the rollers on the cone. The cone, rollers and cage components of our tapered roller bearings are referred to as the cone assembly. Individual cup and cone components of our tapered roller bearings are available as well as the complete assembly. In addition, We offers a variety of configurations to our tapered roller bearings such as single-row, double-row
Tapered Roller Bearing Product number
| Part No. | BOUNDARY DIMENSIONS (in m.m.) | LOAD RATING | LIMITING SPEED (R.P.M.) | MASS | ||||||
| d | D | B | C | T | STATIC (Co) KN | DYNAMIC (C) KN | Grease | Oil | (~ Kg.) | |
| 370A / 362A | 50.8 | 88.9 | 22.225 | 16.513 | 20.638 | 91 | 76.5 | 4300 | 5600 | 0.51 |
| 28580 / 25821 | 50.8 | 92.075 | 25.4 | 19.845 | 24.607 | 116.1 | 84.2 | 4000 | 5300 | 0.7 |
| 455/452 | 50.8 | 107.95 | 29.317 | 27 | 32.557 | 148 | 115 | 3500 | 4700 | 1.34 |
| 3780 / 3720 | 50.8 | 93.264 | 30.302 | 23.812 | 30.162 | 148.9 | 110.9 | 4000 | 5300 | 0.84 |
| 33889 / 33822 | 50.8 | 95.25 | 28.575 | 22.225 | 27.783 | 140 | 107.3 | 3900 | 5200 | 0.88 |
| 45284 / 45220 | 50.8 | 104.775 | 30.958 | 23.812 | 30.162 | 169.7 | 130.3 | 3500 | 4700 | 1.19 |
| 45285 A / 45221 | 50.8 | 104.775 | 30.958 | 23.812 | 30.162 | 169.7 | 130.3 | 3500 | 4700 | 1.21 |
| HM 807010 | 50.8 | 104.775 | 36.512 | 28.575 | 36.512 | 189.6 | 139 | 3600 | 4600 | 1.445 |
| 72200C / 72487 | 50.8 | 123.825 | 32.791 | 25.4 | 36.512 | 190.1 | 155.8 | 2900 | 3900 | 2.142 |
| 539 / 532 X | 53.975 | 107.95 | 36.957 | 28.575 | 36.512 | 191.2 | 149.3 | 3600 | 4800 | 1.5 |
Taper Roller Bearings Applications
We are professional bearing manufacture and supplier.
We have a professional design and technicial team. So we could produce different size bearings according to the customer's requirements.Professional Bearing Quality Testing Equipment To Ensure Bearing.So If have any inquiry about bearings, Welcome to consult us,thanks
