EMC Led Stadium Lighting 120000lm Led Flood Light For Football Field
Flood Lights Item Type and Cool White Color Temperature 1000W Stadium LED Flood Light
| 1. 80% lumen maintenance over 50,000hours |
| 2. Wide Power range: 1000W |
| 3. 110-480Vac input voltage without additional adapter |
| 4. Patent Built-in Serge Protection. |
| 5. TOP chips high efficacy 120lm/w with meanwell driver |
| 6. IP67 waterproof, IK10 impact proof |
| 7. Neutral Salt Spray Resistance |
| 8. Anti-Corression power coating surface treatment |
| 9. Stainless steel brackets material.(Upgradable to SS316) |
| 10. 0-10VDC, DALI and wireless control available |
| 11. DLC, TUV CE RoHS, CB, SAA, LM79 listed |
| 12. High uniformity & color rendering index |
| Photos of Stadium LED Flood Light: |
| Parameter of Razorlux Stadium LED Flood Light: |
| Model | RGL2-1000P | |
| Beam Angle | 15° 20° 30° | |
|
Stable Flux (5700K after 1 hour) |
120000lm | |
| Dimension (mm) | 474*388*982 | |
| LEDs | 900W | |
| Power | Driver | 100W |
| Consumption | Total | 800W |
| Replace HID Lamp | 2200~2500W | |
| Net Weight | 38kg with stainless steel floodlight bracket | |
| Color Temperature | 2700-6500K | |
| Color Rendering | ≥Ra75 (≥Ra80, ≥Ra90 available on request) | |
| Working Life | ≥50000Hrs | |
| Housing Material | Aluminum & Powder coating | |
| Power Supply | Meanwell | |
| IP Class |
IP 65 (Upgradeable to IP 67) |
|
| IK Class |
IK 10 |
|
| Insulation Class | Class I | |
| Working Temperature | -40C ~ 60C / -40F ~ 140F | |
| Working Humidity | 10% ~ 95% | |
| AC Input | 110-480Vac input voltage without additional adapter | |
| DC Input | 100 ~ 400Vdc, 500Vdc ~ 800Vdc | |
| THD | <10% | |
| Power Factor | ≥0.98 | |
| Warranty | LED Module | 5 year |
| Driver | 5 year | |
| Housing | 10 year | |
Advantages of Led Flood Light For Football Field
- Top grade CREE/Samsung led chip
- Meanwell Driver
- Marine grade powder coating housing finish, and 316 stainless steel bracket
- 15, 20, 30, 40, 60, 120, and 140 x 60 multil beam angle option
- Clear tempered glass lens, and reflector make the classical shape lighting
- IP67 and IK10 grade
- Protection grid, visor available for optional
- Anti-glare frosted lens available
- 12V or 24Vdc available
- Support smart control
FAQ:
1. Are you a factory or trading company:
We are a factory located in Xi'an China, established in 2006.
2. What is your product range?
Our wide product range includes floodlight, street light, pendant light, and power from 60W to 1200W.
3. How many days of production will the order take?
Normally 7-15 days, depending on the order quanity.
4. How do you ship goods abroad?
For sample, trial order, or small quantities we will suggest shipping by air, for large quantity and bulk order we recommend shipping by sea.
5. Does your product support smart control like sensor, dimming, DALI, etc.
They support all of these features, please tell our sales during your negotiation when you need such features.
6. How do you deal with failed lights?
During the warranty period, we will send customer free part or lamp after checking the evidence. After warranty, we only charge the component fees, no extra charge for our customer.
