Aluminum Lamp Body 305Vac Marine Led Flood Light 1000w
|
Model
|
|
RGL1000A
|
|
|
Beam Angle
|
|
40° 60° 120° 140°
|
|
|
Stable Flux (5700K after 1 hour)
|
|
130000lm
|
|
|
Dimension (mm)
|
|
671*405*204
|
|
|
|
LEDs
|
900W
|
|
|
Power
|
Driver
|
100W
|
|
|
Consumption
|
Total
|
1000W
|
|
|
Replace HID Lamp
|
|
2200~2500W
|
|
|
Net Weight
|
|
30kg (66lbs)
|
|
|
Color Temperature
|
|
2700-6500K
|
|
|
Color Rendering
|
|
≥Ra75 (≥Ra80, ≥Ra90 available on request)
|
|
|
Working Life
|
|
≥50000Hrs
|
|
|
Housing Material
|
|
Aluminum & Powder coating
|
|
|
Power Supply
|
|
Meanwell
|
|
|
IP Class
|
|
IP 65 (Upgradeable to IP 67)
|
|
|
IK Class
|
|
IK 10
|
|
|
Insulation Class
|
|
Class I
|
|
|
Working Temperature
|
|
-40C ~ 60C / -40F ~ 140F
|
|
|
Working Humidity
|
|
10% ~ 95%
|
|
|
AC Input
|
|
110-480Vac input voltage without additional adapter
|
|
|
DC Input
|
|
100 ~ 400Vdc, 500Vdc ~ 800Vdc
|
|
|
THD
|
|
<10%
|
|
|
Power Factor
|
|
≥0.98
|
|
|
Warranty
|
LED Module
|
5 years
|
|
|
|
Driver
|
5 years
|
|
|
|
Housing
|
10 years
|
|
Features:
1. 80% lumen maintenance over 50,000hours.
2. Wide Power range: 1000W.
3. 110-480Vac input voltage without additional adapter .
4. Patent Built-in Serge Protection.
5. TOP chips high efficacy 130lm/w±7% with meanwell driver.
6. IP67 waterproof, IK10 impact proof.
7. Neutral Salt Spray Resistance.
8. Anti-Corression power coating surface treatment.
9. Stainless steel brackets material.(Upgradable to SS316).
10. 0-10VDC, DALI and wireless control available.
11. DLC, TUV CE RoHS, CB, SAA, LM79 listed.
12. High uniformity & color rendering index.
2. School / Universities / Hospital
3. Conference / Meeting room / Show Room
4. Commercial establishments
5. Factories / Offices
6. Super-markets
7. Residential / Institution buildings
8. Government lighting engineering, airport, subway, elevated overpass, billboard stadium,
9. Building external walls landmarks such as the landscape lighting
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
