350kg Hydraulic Electric Mobile Double Scissor Lift Table Cart 70" Max Height
Hydraulic Scissor Lift Table Double Scissor Table Lifter 70" Max. Height
Features:
- Self lubricating bushings on pivot points.
- Removable lifting eye to facilitable handling and lift table installation.
Description:
Upper platform lifted with aluminum safety bar preventing descent on contact with obstructions.
Low-tention(24V) control box with up-down buttons.
Internal power pack equipped with relief valve against overloading and compensated flow valve for controlled lowering speed.
Heavy duty cylinders with drainage system and check valve to stop the lift table lowering in case of hose burst.
Safety clearance between scissors to prevent trapping during operation.
| Model | HD1000 | HD2000 | HD4000 | |
| Capacity | Kg | 1000 | 2000 | 4000 |
| Lowered Height | mm | 305 | 360 | 400 |
| Raised Height | mm | 1780 | 1780 | 2050 |
| Platform Size | mm | 820x1300 | 850x1300 | 1700x1200 |
| Base Frame Size | mm | 640x1240 | 785x1220 | 1600x900 |
| Lift Time | (sec) | 35-45 | 35-45 | 55-65 |
| Power Pack | 380V/50HZ,AC2.2kw | |||
| Net Weight | kg | 210 | 295 | 520 |
FAQ:
Q: What about the quality of the products?
A: Our lift tables are CE approved, and we have five inspection steps before shipment:
1. Inspect the raw material in accordance with ISO9001;
2. Strict inspection in the whole production process;
3. Load limit test when assembling finished;
4. 100% strict inspection of lift tables before shipment;
5. If needed, inspection by buyer.
Q: Do you accept customized design? Do you offer OEM & ODM service?
A: Yes,of course! We have over 10 years' experience in customized design product,expecially lift tables.
Q: What information should I provide for a customized order?
A: The more information you provide, the accurate solution we can prepare for you.Such as:
1.control by manual or electric
2.stationary or mobile lift tables
3.power source/voltage demand
4.load capacity
5.lifting heigh(min.height and max height)
6.table size
Q: What is your MOQ?
A: One unit.The more the better.The price is negotiable for large quantity.
Q: How long is the quality guarantee?
A: All of our products carry one-year warranty.
Q: What's the leadtime?
A: Normally 30 days.
If you order more than 5 itmes mixed in one container, it will be 45 days.
If you order one item in one container, it will be 20 days.
