Industrial Small Electric Scissor Lift Table Industrial 1700x850mm Maximum Height 50"
CE Certificated Scissor Electric Lift Tables Maximum Height 50"
Main Features:
- Stable scissor lift design.
- With safety bar below table top.
- With anti-explosion valve in oil cylinder.
- Special requirements are customizable.
- HW series lift tables meet EN norm and ANSI/ASME safety standards.
- These models can be used in above-floor or in-floor pit applications.
Description:
The lift table is designed to promote employee safety by lifting loads to a comfortable working height. Meets ANSI standards for Lift Tables. 1 Year Limited Warranty.
Specification:
| Model | Capacity | Lowered Height | Raised Height | Platform Size | Base Frame Size | Lift Time | Power pack | Net Weight |
| kg | (mm) | (mm) | (mm) | (mm) | (second) | (kg) | ||
| HW1001 | 1000 | 205 | 1000 | 820×1300 | 640×1240 | 20-25 | 380v/50HZ,AC1.1kw | 160 |
| HW1002 | 205 | 1000 | 1000×1600 | 640×1240 | 20-25 | 186 | ||
| HW1003 | 240 | 1300 | 850×1700 | 640×1580 | 30-35 | 200 | ||
| HW1004 | 240 | 1300 | 1000×1700 | 640×1580 | 30-35 | 210 | ||
| HW1005 | 240 | 1300 | 850×2000 | 640×1580 | 30-35 | 212 | ||
| HW1006 | 240 | 1300 | 1000×2000 | 640×1580 | 30-35 | 223 | ||
| HW2001 | 2000 | 230 | 1050 | 850×1300 | 785×1220 | 20-25 | 380v/50HZ,AC1.5kw | 235 |
| HW2002 | 230 | 1050 | 1000×1600 | 785×1220 | 20-25 | 268 | ||
| HW2003 | 250 | 1300 | 850×1700 | 785×1600 | 25-35 | 289 | ||
| HW2004 | 250 | 1300 | 1000×1700 | 785×1600 | 25-35 | 300 | ||
| HW2005 | 250 | 1300 | 850×2000 | 785×1600 | 25-35 | 300 | ||
| HW2006 | 250 | 1300 | 1000×2000 | 785×1600 | 25-35 | 315 | ||
| HW4001 | 4000 | 240 | 1100 | 1200×1700 | 900×1600 | 30-40 | 380v/50HZ,AC2.2kw | 375 |
| HW4002 | 240 | 1100 | 1200×2000 | 900×1600 | 30-40 | 405 | ||
| HW4003 | 300 | 1400 | 1000×2000 | 900×2000 | 45-50 | 470 | ||
| HW4004 | 300 | 1400 | 1200×2000 | 900×2000 | 45-50 | 490 | ||
| HW4005 | 300 | 1400 | 1000×2200 | 900×2000 | 45-50 | 480 | ||
| HW4006 | 300 | 1400 | 1200×2200 | 900×2000 | 45-50 | 505 | ||
| HW4007 | 300 | 1400 | 1500×1700 | 1200×1600 | 45-50 | 420 | ||
| HW4008 | 300 | 1400 | 1800×2200 | 1500×2000 | 45-50 | 540 |
Shipment:
FAQ:
Q: What about the quality of the products?
A: Our products are CE approved, and we have five inspection steps before shipment:
1. Inspect the raw material in accordance with ISO9001;
2. Strict inspection in the whole production process;
3. Load limit test when assembling finished;
4. 100% strict inspection of products before shipment;
5. If needed, inspection by buyer.
Q: How long is the quality guarantee?
A: All of our products carry one-year warranty.
Q: What's the leadtime?
A: Normally 30 days.
If you order more than 5 itmes mixed in one container, it will be 45 days.
If you order one item in one container, it will be 20 days.
