ES Series Scissor Q345B Electric Mobile Lift Table Trolley Portable Platform
ES Series Mobile Lift Tables Electric Scissor Lift Trolley
ES series electric scissor lift table is designed for quickly and easily lift and lower loads up to 500kg(1100lbs). Ideal for lifting, positioning , transporting heavy loads shrt distance around the shop, factory, warehouse or even office. With robust structure light weight. capacity from 300 to 800kg with different lifting height.
Battery operated scissor lift table features a proven Curtis contraller and Hall Accelerator to provide effortless lifting, lowering and movement of heavy loads. A push of a button will raise and lower the platform of the electric lift table, 12V DC battery operated unit features an on-board battery charger and maintance battery
Two castors with brakes to increase safety. Power unit made in Euope DC800W. Automatic battery charger.
High quality battery, Single scissor 54 Ah/12V ; Double scissor 80 Ah/12V
This ES series electric lift table has different models with different capacity and lifting height like ES30, ES50, ES75,ES100 and ES30D, ES50D, ES75D, ES100D, so they can meet all kinds of high lift working.
| Model | ES30 | ES50 | ES75 | ES100 | ES30D | ES50D | ES80D | |
| Capacity | kg(lb.) | 300(660) | 500(1100) | 750(1650) | 1000(2200) | 300(660) | 500(1100) | 800(1760) |
| Table size | mm(in.) | 1010*520(40*20) | ||||||
| Table height(Min./Max.) | mm(in.) | 450/950
(19.5/37.4) |
480/950
(19/37) |
495/1600
(20/63) |
495/1618
(20/64) |
510/1440
(20.1/57) |
||
| Lifting Cycle Fully Charged | 65 | 55 | 45 | 40 | 45 | 40 | ||
| Wheel Dia. | mm(in.) | 150(6) | ||||||
| Lifting/Lowering Time | second | 15/22 | 15/18 | 15/20 | ||||
| Overall size | mm(in.) | 520*1230(20*50.2) | ||||||
| Net Weight | kg(lb.) | 140(308) | 148(325.6) | 154(338.8) | 169(371.8) | 183(402.6) | 198(435.6) | 215(473) |
