Aluminum Shell Induction Melting Furnace 1 Ton With Electric Induction Heating

Price Negotiable

Price: 1000USD/set

MOQ: 1 SET

Delivery Time: 2 months

Brand: HYDEB

Product Description

Manufacturer offering Aluminum Shell Induction Melting Furnace 1 Ton with Electric Induction Heating Price available

1. Smelting Crucible Furnace Genernal Introduce
-- Use in all foundries or aluminum die casting area

– Smeltery for feeding holding furnaces or for direct casting.

-- Low heat losses through high-quality insulation

-- No exhaust system needed

-- Accurate temperature control Crucible

-- Standard design for the use of graphite crucible2. Smelting Crucible Furnace Specification Data

SN	Items	Date	Remarks
1	Efficient furnace capacity kg (Al)	580
2	Melting Rate kg/h (Al)	280	Inside the crucible there is already have 1/3 molten aluminum.
3	Maximum furnace temperature ℃	950
4	Precision of molten aluminum temperature control ℃ ≤± 5
5	Temperature control mode	PID+Dual temperature control
6	Crucible type and size mm OD 880, d 350mm, H 1000		BN800 Morgen
7	Furnace surface temperature rise ℃ ≤50		Except for the installation site of the heating tube, the discharge outlet and rising tube
8	Power Source Voltage V/Frequency HZ	380/50
9	Air Pressure MPa	0.5-0.7
