S4KT S4k Diesel Cylinder Block 3064 E312 120B Cylinder Block 5I-7909
S4KT Diesel Engine Parts S4k Cylinder Block 3064 E312 120B 212-8478 5I-5599 5I-7909
Product details
Product Name: Cylinder Block
Engine Model: S4K
No. of Cylinders: 4
MOQ: 1 PCS or 1 Set
Compatible equipment models
EXCAVATOR 311 311C 312C 312C L 314C E110B E120B
Parts for 311-A EXCAVATOR:
|
Pos. |
Part No |
Qty |
Parts name |
Comments |
|---|---|---|---|---|
|
1. |
5I-7909 |
[1] |
CRANKCASE AS |
|
|
2. |
095-2005 |
[2] |
CAP |
|
|
3. |
3P-1896 |
[5] |
PLUG |
|
|
4. |
096-3741 |
[5] |
CAP |
|
|
5. |
5I-7528 |
[1] |
BUSHING |
|
|
6. |
5I-7523 |
[4] |
SLEEVE |
|
|
7. |
5I-7525 |
[1] |
PLUG |
|
|
8. |
5I-7529 |
[1] |
BUSHING |
|
|
9. |
095-2039 |
[1] |
WASHER |
|
|
10. |
8T-4191 |
[1] |
BOLT (16mm LONG) |
|
|
11. |
099-4420 |
[2] |
PIN |
|
|
12. |
5I-7505 |
[5] |
PLUG |
|
|
13. |
5I-7724 |
[2] |
PIN |
|
|
14. |
5I-8009 |
[1] |
BUSHING |
|
|
15. |
5I-7524 |
[2] |
SEAL |
|
|
16. |
5I-7839 |
[1] |
CAP SET-BEARING |
|
|
|
|
|
(UN-FINISHED PARTS) |
|
|
17. |
094-7115 |
[10] |
BOLT |
|
|
18. |
6V-8236 |
[6] |
PIN |
|
|
19. |
095-2011 |
[1] |
CAP |
|
|
20. |
5I-7526 |
[4] |
VALVE |
|
|
21. |
5I-7672 |
[1] |
SHAFT AS |
|
|
22. |
095-0879 |
[1] |
PIN |
|
|
23. |
5I-7588 |
[5] |
BEARING SET (STD) |
|
|
|
5I-7784 A |
[5] |
BEARING SET (0.25mm US) |
|
|
|
5I-7785 A |
[5] |
BEARING SET (0.50mm US) |
|
|
|
5I-7786 A |
[5] |
BEARING SET (0.75mm US) |
|
|
24. |
5I-7654 |
[3] |
PLATE (STD) |
|
|
|
5I-7787 A |
[3] |
PLATE (0.15mm OS) |
|
|
|
5I-7788 A |
[3] |
PLATE (0.30mm OS) |
|
|
|
5I-7789 A |
[3] |
PLATE (0.45mm OS) |
|
|
25. |
5I-8005 |
[1] |
SWITCH |
|
|
26. |
5I-7636 |
[1] |
EYE |
|
|
27. |
5I-7603 |
[1] |
EYE |
|
|
28. |
8T-4179 |
[3] |
BOLT (20mm LONG) |
|
|
29. |
096-2501 |
[3] |
WASHER |
|
|
30. |
5I-7978 |
[1] |
SHEET |
|
|
31. |
4D-7794 |
[1] |
CLIP |
|
|
32. |
7X-2536 |
[1] |
BOLT (14mm LONG) |
|
|
33. |
3B-4505 |
[1] |
LOCKWASHER |
|
|
|
A |
|
NOT PART OF THIS GROUP |
|
