Technical parameters:

• ECG

Lead mode;I,II,III,AVR,AVL,AVF,V1-6

Gain: ×0.25, × 0. 5, and × 1, × 2

Frequency: 0.5 Hz - 100 Hz

Common-mode signal inhibition: More than 70 dB

Scan rate: 12.5 mm / S, 25 mm / S, 50 mm / S standard three stalls.

HR: ± 5 BPM

Precision calibration signal: 1mv(peak, ± 3% accuracy)

ST Detection: measurement range (-2.0mV----+2.0mV)

Using Standard: meet the ANSI / AMI EC13 -2002 standard

Response time: 1s

      Alarm: Sound and Light

      Preset heart rate range: (Alarm over preset numerical)

      Ceiling: 1-255 bpm adjustable

      Threshold: 0-254 bpm adjustable

• NIBP

Technology: Oscillography

Measurement method:more accurate with reverse measurement

Measurement units:mmHg/Kpa

Overvoltage protection:double safety protection

Measure time:less than 45S

Scope: Pressure Cuffs 0-250 mmHg

Measure accuracy:ANSI/AAMI SP10-2002 standard average accuracy and deviation

Inflatable cuffs: 180 mmHg (120mmHg for children

Inflatable cuffs follow: original SBP: + 30 mmHg

Measuring range:

SBP 60 mmHg～250 mmHg

Pmean 45 mmHg～235 mmHg

DBP 40 mmHg～220 mmHg

Measure accuracy:±1.1KPa(±8mmHg)±10%

Response time: 1s

       Alarm: Sound and Light

Preset range: report (Numerical exceed preset alarm)

SBP maximum 1mmHg～255 mmHg

Threshold 0 mmHg～254 mmHg

DBP maximum 1mmHg～255 mmHg

Threshold 0 mmHg～254 mmHg

Alarm accuracy:±1 mmHg

Standard: ANSI/AAMI SP10-2002

• SPO2

Range: 0-100%

Accuracy: 1%

Resolution: 1%

Pulse frequency: 20-250 times / min

Response time: 1s

Alarm: Sound and Light

Preset range: (report Alarm over preset numerical)

Ceiling: 1% - 100% adjustable

Threshold: 0% - 99% adjustable

• TEMP

Technology: thermostat temperature probe

Measuring range: 20 ° C-45 ° C

Temperature resolution: 0.1%

Accuracy: ± 1 ° C

Response time: 1s

      Alarm: Sound and Light

      Preset range: report (numerical preset alarm over)

      Maximum: 20.1 ° C-45.5 ° C adjustable

      Threshold: 20 ° C-45.4 ° C Adjustable

       Alarm accuracy:±1℃

• RESP

      Breathing frequency range: 0-60 bum

      Accuracy: ± 1rpm

      Response time: 1s

      Gains options: × 1, × 2, × 0.5, and × 0.25 four trenches

      Alarm: Sound and Light

Ceiling: 10-100 bpm adjustable

Threshold: 0 -99 bpm adjustable

Alarm accuracy:±1rpm

• System

Screen:12.1 inches TFT screen of LCD

Battery: sealed maintenance-free lithium battery

Safety standard: lec601-1(GB9706.1)
