JIS KS Cast Iron Flanged Globe Valve Black Medium Water Steam Electric
Price:
Negotiable
MOQ:
10PCS
Delivery Time:
5-8 work days
Brand:
Y
Product Description
JIS/ KS Cast Iron Black Color Medium Water Or Steam Flanged Globe Valve
Introduction
Turn on or turn off the pipelines where the working nominal pressure is ≤1.6 MPA . The applicable medium of cast iron stop valve is: water, oil, steam, acid medium, etc. The operation modes are: manual, gear drive, electric, pneumatic, etc
Advantage
1. The utility model has the advantages of simple structure and convenient manufacture and maintenance.
2. Small working stroke and short opening and closing time.
3. Good sealing performance, small friction between sealing surfaces and long service life.
Dimensions
| DN | L | D | D1 | b | Zxфd | Hmax | Hmin | ф |
| 50 | 200 | 155 | 120 | 20 | 4xф19 | 238 | 221 | 180 |
| 65 | 220 | 175 | 140 | 22 | 4xф19 | 265 | 239 | 190 |
| 80 | 240 | 185 | 150 | 22 | 8xф19 | 300 | 269 | 210 |
| 100 | 290 | 210 | 175 | 24 | 8xф19 | 353 | 312 | 240 |
| 125 | 360 | 250 | 210 | 24 | 8xф23 | 413.5 | 353.5 | 260 |
| 150 | 410 | 280 | 240 | 26 | 8xф23 | 483 | 393 | 270 |
| 200 | 500 | 330 | 290 | 26 | 12xф23 | 557.5 | 463.5 | 350 |
