Handel Power Flanged Butterfly Valve Triple Eccentric Hard Seal Ring PN1.0/1.6 Mpa
Price:
Negotiable
MOQ:
10 pcs
Delivery Time:
5-8 work days
Brand:
Y
Product Description
Handel Power Triple Eccentric Hard Seal Ring PN1.0/1.6 Mpa Flanged Butterfly Valve
Introduction
The butterfly plate of the butterfly valve is installed in the diameter direction of the pipeline. In the cylindrical channel of the butterfly valve body, the disc butterfly plate rotates around the axis with a rotation angle of 0 ° - 90 °. When it rotates to 90 °, the valve is fully open
Usage
This valve is suitable the pipelines of water, oil etc. It can adjust and cut off the fluid.
Dimensions
| mm | L | D | D1 | b-f | Z-фd | H | H1 |
| 50 | 108 | 165 | 125 | 2-20 | 4-ф18 | 82 | 384 |
| 65 | 112 | 185 | 145 | 2-20 | 4-ф18 | 92 | 402 |
| 80 | 114 | 200 | 160 | 2-20 | 8-ф18 | 100 | 407 |
| 100 | 127 | 220 | 180 | 2-22 | 8-ф18 | 110 | 434 |
| 125 | 140 | 250 | 210 | 2-22 | 8-ф18 | 125 | 506 |
| 150 | 140 | 285 | 240 | 2-24 | 8-ф22 | 140 | 546 |
