GOST Cast Iron Flanged Gate Valve With Handle Full Port Lightweight
Price:
Negotiable
MOQ:
10 pcs
Delivery Time:
5-8 work days
Brand:
Y
Product Description
GOST Cast Iron Light Body Handle Power Rising Stem Flanged Gate Valve
Usage
Turn on or turn off the pipelines were the nominal pressure is ≤1.0 mpa and the medium must be steam, water or oil, which can be used in fields of petroleum industry, chemical industry, pharmaceutical industry and power industry
Main part and material
| Name | Material |
| Body and bonnet | Iron |
| Disc | Iron |
| Stem | 2Cr13 |
| Handel wheel | Iron |
Dimension
| DN | L | D | D1 | b-f | Zxфd |
| 50 | 180 | 160 | 125 | 17-2 | 4xф18 |
| 80 | 210 | 195 | 160 | 19-2 | 4xф18 |
| 100 | 230 | 215 | 180 | 19-2 | 8xф18 |
| 150 | 280 | 280 | 240 | 21-3 | 8xф23 |
| 200 | 330 | 340 | 295 | 23-3 | 12xф23 |
| 250 | 450 | 395 | 350 | 26-3 | 12xф23 |
| 300 | 500 | 445 | 400 | 26-3 | 12xф23 |
