Flange Type Globe Valve Ductile Iron Regulating Electric Actuator Power
Price:
Negotiable
MOQ:
10 pcs
Delivery Time:
5-8 work days
Brand:
Y
Product Description
Ductile Iron Regulating Valve Pressure 1.6 Mpa Flanged Globe Valve
Usage:
This valve is mainly used in water network, power plant, water diversion project and other media as the water pipe network system, to adjust the pipe medium flow, flow state and decompression and pressure regulation, especially in large diameter, high pressure and large pressure difference The working condition shows its superior adjustment and control functions.
Main parts and materials
| Body ,Outlet valve body | Ductile Iron |
| Cage,Piston,Connecting rod | Stainless steel |
| Seat ,stem | Stainless steel |
| Ring | NBR |
Function
| Type | TL941X-16Q |
| Pressure | 1.6 mpa |
| Shell test (water) | 2.4mpa |
| Seal test (water) | 1.76 mpa |
| temperature | 0~80℃ |
| medium | raw water |
