Supermarket Metal Retail Shelving Retail Acrylic Display Stands ODM
Grocery Store Retail Display Stand Racks Gondola Shelving Supermarket Shelf Metal Retail Shelving
Euro Style:
| Basic shelving components | Size | options(mm) |
| Upright | Section size/ | 30x30/ 30x60/ 30x80/ 30x110 |
| Lenght/ | 1410/1510/1610/1710/1810/1910/2010/2110/2210/2310/2410/ | |
| 2510/2610/2710/2810/2910/3010 | ||
| Thickness/ | 2.0/ 2.5 | |
| Base leg | Length | 200/250/300/370/470/570/670/770 |
| Height | 60/110/160/260 | |
| Shelf | Width | 665/800/1000/1250/1330 |
| Depth | 200/250/300/370/470/570/670/770 | |
| Thickness | 0.7/0.8 | |
| Wire shelf | Width | 665/1000/1250/1330 |
| Depth | 370/470/570 | |
| Dia | 2.8 | |
| Preforated backpanel | Width | 665/800/1000/1250/1330 |
| Height | 400/500 | |
| Thickness | 1.0/1.2 | |
| Back panel | Width | 665/800/1000/1250/1330 |
| Height | 100/200/300/400/500 | |
| Thickness | 0.6/0.7 | |
| Bracket | Hook number | 2/3/4 |
| Length | 200/250/300/ 370/470/570/670/770 | |
| Thickness | 2.5/3 |
American style:
| Basic shelving components | Size | options |
| Upright | height | 30'' thru 120'' in 6'' (152 mm) incremnets |
| Kicker plate | Length | 2' to 4' in 6'' increments |
| Top/bottom spanner | Width | 3' or 4' |
| Hardboard Backs | height | 6”, 12”, 18”, 24”, 30”, 36”, 42”, 48”, 54”, 60”, 66”, 72" |
| (Pegboard and Marteck) | Length | 2' to 4' in 6'' increments |
| Shelf | Width | 2' to 4' in 6'' increments |
| Depth | 7''-31'' | |
| Angular adjustment | flat, 17° or 30° downslope positions | |
| Base Shelf | Width | 2' to 4' in 6'' increments |
| Depth | 7''-31'' | |
| Wire shelf | Width | 2' to 4' in 6'' increments |
| Depth | 7''-31'' | |
| Angular adjustment | flat, 17° or 30° downslope positions |
Australian style:
| Basic shelving components | Size | options(mm) |
| Upright(single side) | Depth | 200/250/300/320/350/400/450/500 |
| Height/ | 1200/1500/1800/2100/2400 | |
| Thickness/ | 1.5/ 2.0 | |
| Shelf | Width | 600/630/900/930/1200/1230 |
| Depth | 200/250/300/320/350/400/450/500 | |
| Thickness | 0.5/0.6/0.7/0.8/0.9/1.0 | |
| Wire shelf | Width | 600/630/900/930/1200/1230 |
| Depth | 335/405 | |
| Dia | 2.7 | |
| Preforated backpanel | Width | 600/630/900/930/1200/1230 |
| Height | 100/300 | |
| Thickness | 0.7/0.8/0.9/1.0/1.2 | |
| Back panel | Width | 600/630/900/930/1200/1230 |
| Height | 100/300 | |
| Thickness | 0.6/0.7/0.8/0.9 | |
| Volcano back panel | Width | 600/630/900/930/1200/1230 |
| Height | 100/300 | |
| Thickness | 0.8/0.9/1.0 | |
| Mesh back | Height | 1200/1500/1800/2100/2400 |
| Width | 600/630/900/930/1200/1230 | |
| Bracket | Hook number | 2/3/ |
| Length | 250/300/ 320/350/400/450/500 | |
| Thickness | 2.0/2.5/3 | |
| Rear/ front beam | Length | 600/630/900/930/1200/1230 |
| Wire fence | Length | 600/630/900/930/1200/1230 |
Asia Style:
| Basic shelving components | Size | options |
| Upright | Section | 30*60*2.0mm; 30*80*2.2mm; |
| height | 1350;1550;1850;2150;2550mm | |
| Kicker plate | Length | 500; 650;700;800;900;1000;1100;1200;1300mm |
| Flat back panel | height | 300mm; 150mm |
| Length | 500; 650;700;800;900;1000;1100;1200;1300mm | |
| Pegboard panel | height | 300mm; 150mm |
| Length | 500; 650;700;800;900;1000;1100;1200;1300mm | |
| Thickness | 0.5; 1.2mm | |
| Shelf | Width | 500; 650;700;800;900;1000;1100;1200;1300mm |
| Depth | 200; 300;350;400;450;500;550;600mm | |
| Angular adjustment | flat, 17° or 30° downslope positions | |
| Base Shelf | Width | 2' to 4' in 6'' increments |
| Depth | 7''-31'' | |
| Bracket | Length | 200; 300;350;400;450;500;550;600mm |
| Thickness | 2.5; 3mm |
Distributed to 90 countries worldwide. Designed and manufacture exclusively for export from China to all over the world. Complete raw materials and processing production supply system. More than 12 years’ processing and molding experience in sheet /pipe / wire made of steel, aluminum and stainless, as well as wooden products. Complete shop equipment and furniture structure design team and production team. Stable and on-time delivery. Excellent after-sales customer service. Provide products that meet customers’ specifications and excellent quality. Fast product structure design mapping. Short-term accurate quotations and product drawings provide. Provide prototype for approval before mass production
Are you a manufacturer or trader?
We are a 10 years experience factory. We try our best to provide competitive price and professional service.
What surface treatment do you handle?
Powder coating, zinc plating, polished, paint, anodic oxidation etc.
Can you customize my products?
We can customize kinds of machinery parts according to your idea or requirement.
What about your quality control?
We have scheduled process audits and routing /final inspections. All products should pass strict QC before shipping to our customers.
What’s the surface treatment type can you handle?
Powder coating, painting, polish, brushed, galvanized, anodized, sand blasting.
Can I print my own brand logo on your product?
OEM orders are highly welcome. Please offer us the details of your logo, and position when you send us inquiry.
