Board Male M12 4 Pin Aircraft Connector Waterproof Aviation Plug
Board Male M12 4 Pin Aircraft Connector Waterproof Aviation Plug
-
The aviation head, or aviation plug, is a mechanical and electrical component connected to an electrical circuit.
Aviation plug can also be called plug seat, widely used in all kinds of electrical lines, plays the role of connecting or disconnecting circuits. Improving the reliability of aviation plugs is first and foremost the responsibility of the manufacturer. However, due to the variety of aviation plug, a wide range of applications, therefore, the correct choice of aviation plug is also an important aspect to improve the reliability of aviation plug. Only through the joint efforts of both manufacturers and users can the aviation plug be fully functional.
-
Aviation plugs are classified in different ways. According to frequency points, there are high frequency aviation plug and low frequency aviation plug; According to appearance cent has circular connector, according to use cent: cabinet uses aviation plug, sound equipment uses aviation plug, power supply aviation plug, special use aviation plug and so on.
-
The technical parameters of the aviation plug are usually three categories:
①Electrical performance: rated voltage, rated current, contact resistance, voltage resistance and insulation resistance, shielding, rf anti-interference attenuation value
②Mechanical properties: contact number and pinhole, installation and shape, shell material, insulation, contact, mechanical life, etc.
③ Environmental technical performance: working temperature, working height, vibration, impact, constant acceleration, sealing, anti-salt spray, anti-humidity, anti-mould performance, etc.
|
Plastic material |
73T3J |
|
Color |
Black |
|
Insriator Material |
Polyester(UL94V-0) |
|
Contact Material |
Brass,Phosphor Bronze |
| The shell material | Zinc Alloy |
|
Contact Plating |
Tin or silver platedover Ni |
|
Current Rating |
4P(5Amps),6P(3Amps) |
|
Withstanding Voltage |
AC1500Vmin/Minute |
|
Insulation Resistance |
2000MΩ Min |
|
Contact Resistance |
10mΩ MAX |
|
Operation Temperature |
-55℃to+120℃ |
Shenzhen Soulin Eletronics Technology Co.,Ltd.establish in 2009,is a high -tech enterprise which specializes in the manufacturing and marketing of pin header,female header ,box header,SATA connector,BTOB connector,cable,RJ45,DIN41612,and aviation connector.Since the establish of the company,we have been and remain committed to becoming the industry leader for connectors.
The factory with area of 6000 square meter and has about the total number of employees 200 people and own 32 precision mold processing equipment,35 set high-speed precision punch,110sets of automated assembly machines.
All of products compliant “ROHS” and “REACH”,and also we can offer OEM manufacturing services and can meet customer demands with punctual delivery and perfect,We are looking forward to setting up business partnership with customer worldwide.
1) Your inquiry will be replied within 12 hours.
2) We provide OEM, ODM service, the details of the product can be made as your requirement.
3) Excellent before service and after service.
4) Factory and trade integration,18 years export experience
5) One-stop shopping
