6 Layer Multilayer Printed Circuit Board TG135 2oz Double Sided Fr4 Pcb
6 Layer Multilayer Printed Circuit Board TG135 2oz Double Sided Fr4 Pcb
Multilayer Printed Circuit Board Integrated Circuit Board Circuit Board Components Electronics Circuit Board
FR4 Printed Circuit PCB Board
This item is a 6 layer printed circuit board.
Panel size: 350* 283MM
PCB Material type: TG135, FR4
The finished board thick is 1.6mm.
The finished copper thickness of this item is 2/1/1/1/1/2oz finished.
The bow and twist tolerance is 0.075%.
The Min drilling size of this item is 0.3mm.
PCB track/gap of this item is 4mil.
The solder mask color of both sides is green.
The silkscreen color of both sides is white.
PCB surface: ENIG 2u"( lage au area)
| PCB Layer6 | L PCB |
| PCB surface | ENIG 2u"(large au area) |
| PCB material | TG135,TG135 |
| PCB thickness | 2.0mm |
| Finished copper | 2/1/1/1/1//2oz |
| Min. hole |
0.3mm |
| Outline | Routing |
| PCB solder mask | Green, both side |
| PCB silkscreen | White, both side |
FAQ:
1. What service can you provide?
Printed Circuit board, Printed Circuit Assembly, Rapid Prototype order
2. How fast is your lead time?
HDI board fastest 3 WDs, 2L and 4L Rigid board fastest 24H
3. How to get quick quotation?
Please provide gerber file and details of the board(including layer, board thickness, copper thickness, surface treatment, solder mask and silkscreen color, special request if any, demand quantity, etc)
Sample:
| PCB Layer | 4L |
| PCB surface | ENIG |
| PCB material | FR4, TG135 |
| finished Copper thickness | 2/2/2/2oz |
| solder mask color | Double side, red |
| Silkscreen | Double side, black |
| Quantity | 1000pcs, 2 weeks |
4.What payment terms do you have?
T/T
