FR4 TG170 Multilayer Printed Circuit Board
FR4 TG170 Multilayer Printed Circuit Board
Multilayer Printed Circuit Board Copper Filled Printed Circuit Board Gold Finger Supplied Stack-Up 12L PCB
12L Multilayer Rigid Printed Circuit Board
Board type: Multilayer Printed Circuit board(12L)
Surface finished: Immersion gold 2u" (0.05 - 0.1 µm gold over 3 - 5 µm of Nickel.) and gold finger
Finished PCB thickness (mm): 2.2mm, +/-10%
Specific raw material requirements: FR4, TG170
Copper weight of outer layer: 1 oz (35µm) Finished Copper Weight
Copper weigh of inner layer: 1/2 oz (18µm) Base Weight
Plating thickness of through hole: 25 microns
Impedance control: Yes
Countersink hole/ coutersunk hole:No
Counterbore hole: No
Smallest hole is 0.2mm
PTH hole tolerance: +/-0.075mm
Solder Resist: 2 Sides, blue
Silkscreen: 2 Sides, white
Circuit profile: V-CUT and routed
E-test request: all PCBs be e-tested
IPC class: 3
Special requirements: Copper filled vias and supplied stack-up
| PCB Layer | Multilayer Printed Circuit board(12L) |
| PCB surface finished | Immersion gold 2u" (0.05 - 0.1 µm gold over 3 - 5 µm of Nickel.) and gold finger |
| PCB material requirement | FR4, TG170 |
| PCB thickness finished | 2.2mm finished, +/-10% |
| Smallest hole size | 0.20mm |
| PCB solder resist | 2 sides, blue |
| PCB silkscreen color | 2 sides, white |
| Copper weigh of outer layer | 1 oz (35µm) Finished Copper Weight |
| Copper weigh of inner layer | 1/2 oz (18µm) Base Weight |
| Special requirements |
Copper filled vias and supplied stack-up |
FAQ:
1. What service can you provide?
Printed Circuit board, Printed Circuit Assembly, Rapid Prototype order
2. How fast is your lead time?
HDI board fastest 3 WDs, 2L and 4L Rigid board fastest 24H
3. How to get quick quotation?
Please provide gerber file and details of the board(including layer, board thickness, copper thickness, surface treatment, solder mask and silkscreen color, special request if any, demand quantity, etc)
Sample:
| PCB Layer | 4L |
| PCB surface | ENIG |
| PCB material | FR4, TG135 |
| finished Copper thickness | 2/2/2/2oz |
| solder mask color | Double side, red |
| Silkscreen | Double side, black |
| Quantity | 1000pcs, 2 weeks |
4.What payment terms do you have?
T/T
