TITAN Unmanned Boat Small Boat For Pond Maintenance Water Surface Mowing Robot
TITAN Unmanned Mowing Boat Surface Robot Weed Cutting Boat
TITAN unmanned mowing boat has functions such as fully automatic waterweed harvesting, water surface cleaning, water quality inspection, etc. The main application scenarios are lakes, inland rivers and other waters.
Core functions:
waterweed harvesting, water quality monitoring, intelligent route planning, full load of garbage, and return to the sea.
Product advantages:
| Dimension | TITAN 100 | Traditional labor | Semi-automatic machinery |
| Maintenance area | 24.7acres/boat | 3.2acres/person | 16.4acres/person |
| Length of work | 16h/day | 6h/day | 6h/day |
| Safety | Driverless, 100% safe | People + tools, high labor risk | Manned driving, driving risk is high |
| Response efficiency | 24h online response | Working time response | Working time response |
| Energy consumption | Clean energy, charging at night, working during the day | Manpower | Gasoline energy, need to be purchased at the petrol station |
| Quality of work | Consistent harvest depth, no omissions | Inconsistent harvest depth, affected by environmental changes | Affected by work status and attitude |
| Skill requirements | Smart machine operation, easy to use, no certificate required | Skilled in using tools, skilled in ferrying boats, swimming license required | Skilled in mechanical boat driving, swimming license required, crew certificate required |
|
Response efficiency |
24 hours response |
Product Highlights:
1. Radar Slam: SLAM mapping based on millimeter wave radar, get rid of the constraints of GPS signals, and achieve 0.8m precise welt.
2. Multiple functions: Mainly cleaning function, standardized water quality, water depth, inspection and detection multiple modules, which can be quickly matched to meet the needs of all-weather and all-scene maintenance in the water area;
3. Image Identification: Accumulatively trained more than 100 kinds of characteristic targets to achieve accurate recognition of various targets such as surface garbage, people falling into the water, and shoreline pedestrians.
| Hull size|Length, width and height/mm (extension arm not included) | Length 3150 × width 1660 × height 1480 |
| Hull size|Length, width and height/mm (standard 1m extension arm) | Length 4030 × width 2380 × height 1480 |
| Hull material | Aluminum alloy |
| Hull weight (no load) | 430kg |
| Rated load | 100kg |
| Charging time | 5 hours |
| Battery life | 8 hours |
| Rated storage volume | 0.45m³ |
| Working minimum water depth | 800mm |
| Safety protection and dustproof design | IP55 |
Configuration service:
Basic Configuration: silver metal charging cabinet
Optional modules: water quality monitoring module, coastal flushing module, garbage weighing module
Since its establishment, OrcaUboat has focused its research on the core technology of surface unmanned driving. The technology has been systematic, and the field of surface maintenance has been deeply digged. Starting from multiple specific scenarios, it has developed such as water surface situation perception and complex water conditions. Trajectory control and decision-making after information collection. After many experiments, research and development and iteration, great progress has been made on these three levels. These three technical levels are basically in the lead in the industry. In addition, the product design is highly integrated.
FAQ
Do you have a back-end management system?
ORCAUBOAT self-developed the front-end system for front-line sanitation workers and the back-end system for management personnel. It is the only unmanned ship manufacturer that can control the ship through the mobile phone APP, and the front-line sanitation workers can use it with very simple operations; Managers can also view the ship's working and operating status in real-time on the back-end system.
