Product Description:
Assun brush DC motor is especially suitable for your portable small equipment. Our hollow cup motor technology continues to innovate, with high motor efficiency and high power to weight ratio.
Product introduction:
AM-CL1643MAN-0907
1.Coreless Metal Brush DC motor diameter 16mm. length 43mm. 9V.
2.Nominal voltage : 9V. No load speed ±12%: 6878 rpm.
3.No load current Max150% : 24 mA. Max cont.torque: 5.3mN.m. Rated Speed : 5462 rpm.
4.Rated Current: 450 mA. Rated Power: 3.0 W. Starting current : 2093 mA. Stall Torque : 26 mN.m.
5. Maximum power output : 4.6W. Maximum Efficiency : 80 %. Terminal resistance ±12% : 4.3Ω.
6.Weight : 40.1g.
7.DC Coreless Metal Brushed motor can install the corresponding with Encoder and Planetarty gearbox.
Product Details:
| Motor Model | AM-CL1643MAN-0907 | Unit |
| Nominal voltage | 9 | V |
| No load speed ±12% | 6878 | rpm |
| No load current Max150% | 24 | mA |
| Max cont.torque | 5.3 | mN.m |
| Rated Speed | 5462 | rpm |
| Rated Current | 450 | mA |
| Rated Power | 3.0 | W |
| Starting current | 2093 | mA |
| Stall Torque | 26 | mN.m |
| Maximum power output | 4.6 | W |
| Maximum Efficiency | 80 | % |
| Terminal resistance ±12% | 4.3 | Ω |
| Inductance (1KHz) | 0.24 | mH |
| Mechanical time constant | 8.7 | ms |
| Moment of inertia | 3.07 | gcm² |
| Torque constant | 12.4 | mN.m / A |
| Speed constant | 773 | rpm / V |
| Speed / torque gradient | 269 | rpm / mN.m |
| Weight | 40.1 | g |
Recommended Gearbox:
Planetary Gearbox : AM-16GP. AM-20GP.
Recommended Encoder :
Encoder S : AM-EN1611S***
2~3 Channels.
Appliation:
Assun Motor application of positive element brushless precision servo motor in intelligent equipment
Motor data tested at 25℃.Motor operation exceeding continuous limits will reduce life or result in damage.
At elevated ambient temperature.load current must be reduced.
