Portable Handheld Optical Power Meter VFL With 5km / 10km Laser Source Visual Fault Locator
Price:
Negotiatable
MOQ:
50 Pieces
Delivery Time:
Negotiable
Brand:
Fongko
Product Description
Product overview
2 IN 1 Fiber Optic Power meter with 5km Laser source Visual Fault locator.This kind calibration type optical power meter is for handheld installation, operation and maintenance of optical fiber network special design of a precise, durable, convenient portable test instrument. With clever appearance, can choose to switch back light display, automatic shutdown function, super wide optical power test range, accurate testing accuracy and new users auto-calibration function and general interface design
Features
1. Support lighting
2. Support automatic shutdown
3. Support backlight switch
4. Supporting Wavelength Memory Function
6. Support user calibration
7. Supporting simultaneous display of linear mW and non-linear index dBm
8. Supporting SCFCST Interface
9. Supporting external power supply such as charging treasure, computer, etc.
10. Supporting simultaneous linear (mW) and non-linear (dBm) display
11. Changing, work 72 hours (optional)
12. Supporting RJ45 testing (optional)
2. Support automatic shutdown
3. Support backlight switch
4. Supporting Wavelength Memory Function
6. Support user calibration
7. Supporting simultaneous display of linear mW and non-linear index dBm
8. Supporting SCFCST Interface
9. Supporting external power supply such as charging treasure, computer, etc.
10. Supporting simultaneous linear (mW) and non-linear (dBm) display
11. Changing, work 72 hours (optional)
12. Supporting RJ45 testing (optional)
| Wavelength range(nm) | 800-1700 | 800-1700 |
| Connector | FC/SC/ST | FC/SC/ST |
| Type of connector | InGaAs | InGaAs |
| Power measurement range(dBm) | -70~+6 | -50~+26 |
| Uncertainty | ±5% | |
| Standard wavelength (nm) | 850,980,1300,1310,1490,1550,1625,1650 | |
| Display resolution | Linear display: 0.1% logarithmic display: 0.01 dBm | |
| 650nm light source (Options) | 1mw/10mw/20mw/30mw/50mw | |
| Operating temperature (C) | -10~+60 | |
| Storage temperature (C) | -30~+70 | |
| Automatic shutdown time (min) | 10 | |
| Continuous working hours of batteries (h) | ≥72 | |
| Instrument size (mm) | 112x66x30 | |
| Power Supply | Two Segment 7 Batteries/ Rechargeable Lithium Batteries (Options) |
|
| Instrument Net Weight (g) | 140/150 | |
