5.8G 40CH FPV Goggles 5 Inch Plastic DVR Video Glasses Professional Drone Accessories
5.8G 40CH FPV Goggles 5 Inch Plastic DVR Video Glasses Professional Drone Accessories
Feature:
● With DVR, you can record videos anytime and anywhere;
● Low power consumption;
● Double module reception to make the signal more stable;
●Auto-Searching, support a key search frequency;
● 5 Inch 800*480 dot high brightness LCD screen;
● Built-in super sensitiveness 5.8GHz 40ch receiver, especially with RaceBand;
● Built-in 7.4V/1430mAh high-capacity Li-ion polymer Battery;
● Universal DC055 charging interface;
● Real-time video return, Very low time-delay;
● The menu supports 8 languages;
● Support external video signal input;
● Support Audio signal output (You can connect headphones)
Thank you for your choose and buy the products of this company.
Specification:
| Model | |||||||||
| Name | 5.8G FPV Goggles | ||||||||
| LCD Screen | Screen size: 5 Inch | ||||||||
| Resolution: 800*480 | |||||||||
| Display Ratio: 16:9 | |||||||||
| View Angle: 6 o'clock | |||||||||
| Brightness: 300cd/m² with high brightness backlight LED | |||||||||
| Video delay | Video time-delay less than 20ms | ||||||||
| Lens | 2.8X Fresnel Lens, 92% transparent rate no distort of light | ||||||||
| Interface | Antenna | 2 X RP-SMA male | |||||||
| DC055 | To charge the battery | ||||||||
| AV Jack | External video signals input or internal Audio signal output | ||||||||
| Card slot | TF-Card, Support up to 32G(C10 recommend) | ||||||||
| DVR | REC size: VGA / D1 / HD Selectable | ||||||||
| REC sound: ON / OFF Selectable | |||||||||
| REC time: OFF / 3min / 5min / 10min Selectable | |||||||||
| Frame rate: 30 Frames | |||||||||
| Compress format: MJPEG | |||||||||
| Record file format: AVI | |||||||||
| Languages | English,German,French,Spanish,Italian,Chinese,Russian,Japanese | ||||||||
|
Power Supply |
Power adapter: DC12V/2A (DC055 interface) | ||||||||
|
Battery: 7.4V/1430mAh, DVR module ON: Each full charge revive around 2.5hr working time DVR module OFF: Each full charge revive around 3.5hr working time |
|||||||||
|
Power Consumption: * Normal mode: The device operating current of 400mA at 3.7V; * Record Mode : The device operating current of 620mA at 3.7V; * Built-in battery maximum charge current of 800mA; |
|||||||||
| Wireless | Frequency Table(MHz) | ||||||||
| CH1 | CH2 | CH3 | CH4 | CH5 | CH6 | CH7 | CH8 | ||
| Band A | 5865 | 5845 | 5825 | 5805 | 5785 | 5765 | 5745 | 5725 | |
| Band B | 5733 | 5752 | 5771 | 5790 | 5809 | 5828 | 5847 | 5866 | |
| Band E | 5705 | 5685 | 5665 | 5645 | 5885 | 5905 | 5925 | 5945 | |
| Band F | 5740 | 5760 | 5780 | 5800 | 5820 | 5840 | 5860 | 5880 | |
| Band R | 5658 | 5695 | 5732 | 5769 | 5806 | 5843 | 5880 | 5917 | |
| Body | Dimension: 180mm * 140mm * 84mm | ||||||||
| Weight: 410g(with headband, not included antennas) | |||||||||
Safety instruction:
- Read the entire instruction manual to become familiar with the features of the product before operating.
- Age Recommendation: Over 14 years old. Using any near eye displays on children under 14 can cause eye development problems. This is not a toy.
- Please avoid wet or humid environments.
- Please use standard DC055 charger, charging voltage can only be DC12V.
- Audio output and Video input cannot work at the same time.
Support and Services:
The Analog Video Transmitter product technical support and services include:
- Expert technical advice and troubleshooting assistance
- Access to product documentation and manuals
- Repair and maintenance services
- Warranty and replacement options
- Upgrades and software updates
- Training and educational resources
FAQ:
Q1: What is the brand name of the Analog Video Transmitter?
A1: The brand name of the Analog Video Transmitter is Kimpok Technology/OEM.
Q2: What is the model number of the Analog Video Transmitter?
A2: The model number of the Analog Video Transmitter is KP-A4.
Q3: What certifications does the Analog Video Transmitter have?
A3: The Analog Video Transmitter is certified with CE/ROHS/FCC/SGS.
Q4: What is the minimum order quantity for the Analog Video Transmitter?
A4: The minimum order quantity for the Analog Video Transmitter is 1 set.
Q5: What are the payment terms for the Analog Video Transmitter?
A5: The payment terms for the Analog Video Transmitter are T/T, PayPal or western Union.
