18TPH Animal Feed Production Line Ring Die Feed Pellet Production Machine
Animal Feed Production Line Ring Die Feed Pellet Production Machine
Parameter of animal feed production machine
| Model | Power(kw) | Capacity(t/h) | Directions | Application |
| SZLH250 | 22 | 0.6-1.0 | According to the customer's different materials and the relative output of different particle sizes, the output of large particles is high, and the output of small particles is small. | Granular processing of various livestock and poultry feeds, aquatic feeds, grass meal and organic fertilizers, and processing of aquaculture feeds such as complete sets of units. |
| SZLH320 | 37 | 1.0-3.0 | ||
| SZLH350 | 55 | 3.0-5.0 | ||
| SZLH420 | 110 | 8.0-10.0 | ||
| SZLH508 | 132 | 10.0-18.0 |
Introduction:
Ring die pellet mill is the main feed machinery equipment for producing pellet feed, its performance determines the feed production to a large extent, and occupies a very important position in the process of feed processing. The machine has reasonable structure, advanced technology, high output, low power consumption, gear transmission, stepless speed regulation feeding, and appropriate amount of steam, molasses, grease and other materials can be added as needed.
Zhengzhou shenghong heavy industry technology co.,ltd. (short for “Shenghong Heavy Industry”)
is recognized globally as an expert in process design and equipment manufacturer on feed industry, including feed pellet production line with 5000 to 100000 tons per year and powder feed production line with 5000 to 200000 tons per year.Ou
How to use feed pellet machine?
1. Before using the feed pellet processing machine, carefully check whether the screws of each part of the equipment are tightened.
2. Before starting the motor, loosen the adjusting screws at both ends of the pressure roller and observe whether the transmission mode of the machine is consistent with the marking.
3. The moisture content of feed ingredients should be around 15%. Too high or too low moisture content will affect the yield and quality of pellets.
4. Hard impurities should be removed from feed raw materials to avoid damage to the machine.
5. The feeding must be stopped before shutdown. After the material in the granulation chamber is processed, add oily material and press it into the template hole.Keep the inside of the hole smooth to avoid clogging in the next use.
