Full Color Advertising Outdoor Led Screen P8 Led Digital Signage SMD3535
Full Color Advertising Outdoor Led Screen P8 Led Digital Signage SMD3535
Quick Installation Half Outdoor Front Service P8 Led Digital Signage
Product description
1. Designed for working in all weather outdoor environments. High protection grade of IP65 suitable for winter and cold areas like North European countries and Russia, and high temperature like KSA, Oman, UAE, etc.
2. There are quick locks on the top and bottom and left and right sides of the box. Installation is faster. Better flatness and consistency.
3. The refresh rate of the whole screen can reach more than 3840Hz, the gray level can be adjusted arbitrarily within 65536, and the video can be played,High definition, can achieve the column and column elimination, no stripes, no caterpillar and other phenomena.The brightness reaches above 5500nit
4. The cabinet can be compatible with a variety of module models,P2.5 P3 P4 P5 P6 P8 P10(320x160mm) can be replaced directly..
5. Savings in Electricity Costs,300 Sqm, 5 years , Save $200,000 on Electricity Costs
6. Stage,Sports,advertising,traffic,events,stadium,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, entertainment,etc.
| Pixel Pitch | 8mm | |||
| LED Lamp | SMD3535 | |||
| LED configuration | SMD 3 in 1 | |||
| Module Size | 320mm x 160mm | |||
| Module pixels | 40x20dots | |||
| Cabinet Size(WxHxD)(mm) | 960x960x108mm | |||
| Module Quantity(pcs) | 18 | |||
| Cabinet resolution WxH | 120x120dots | |||
| Cabinet Material | magnesium alloy | |||
| Cabinet Weight (kg) | 29 | |||
| Average Power/sqm (watts) | 240 | |||
| Max Power/sqm(watts) | 800 | |||
| Brightness | 6500cd/㎡ | |||
| Viewing Angle | H:160°, V:120° | |||
| Best Viewing Distance | 8-200 meters | |||
| Brightness Control | 256 level | |||
| Gray scale | 14 bit | |||
| Refresh frequency | 1920hertz | |||
| Driving mode | 1/5 scan | |||
| Input power frequency | 50 or 60 Hertz | |||
| Input Voltage | 110 ～ 240 Volt,60Hz | |||
| Blind spot rate | ＜1/10000 | |||
| Lifetime at 50% brightness | 100000 hours | |||
| Ingress Protection | IP65 | |||
| Operating temperature | ﹣20 ～﹢60 ℃ | |||
| Operating humidity | 10％ ～ 90％ | |||
| Control distance | CAT5 cable:＜100 m; Single mode fiber:＜10 km | |||
| Signal input format | HDMI,DVI,SDI,VGA etc. | |||
| Operating system | Windows (2000/XP/Vista/7/8/10) | |||
FAQ
Q1: Are you a manufacturer or trading company?
A1: We are a Professional OEM/ODM manufacturer which has specialized in led display industry for more than 15 years.
Q2: How does your factory do regarding quality control?
A2: Quality is priority. Brighter people always attach great importance to quality controlling from the very beginning to the very end. We focus on every detail,Our factory has gained ISO9001, ISO14001, CE, RoHS ,FCC authentication.
Q3: What is your MOQ?
A3: Any quantity is acceptable for your order. And the price is negotiable for large quantity.
Q4: When will you make the delivery?
A4: We can make the delivery within 3-5 working days for the led modules and 10-12days for the led finished screen according to the size and quantities of your order.
Q5: What technical supports can you offer?
A5: We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory. we can send an engineer team to the country of the customer to instruct the installation.
Q6: How long is the warranty?
A6: The standard warranty is 2 year. It could be longer upon request.
Q7: Do you provide any free spare parts in each order?
A7: Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED lamp, IC, mask, power supply, receiving card, etc.
