PLC FTTH Distribution Box Slot Cassette OEM Telephone Terminal Box
OEM FTTH plc Distribution Terminal Box With Slot Cassette
Product Introduction Fiber optic distribution box applied to FTTH that links in the access of the terminal system, especially suitable for the outdoor wall hanging or hoop type. Feature * Design of double layer structure, the upper layer is the optical splitter wiring layer, the lower layer is the fiber fusion layer. * Easy to operate. Usually installed as wall mounted in the building or at the green belt. * The optical splitter module is designed of modular drawer type, and it has high interchangeability and generality. * SMC complex plastic or Cold rolled plate without material optional. * Fixed cable and protection. * Protect optical fiber splice joint. * Termination function of fiber core. Application * Telecommunication Networks. * Communication System. * Test Equipment. * Fiber CATV. * FTTH.
| 1x N | ||||||||
|
Parameter |
Unit |
Specification | ||||||
| 1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | |||
| Operate wavelength | nm | 1260-1650 | ||||||
| Insertion loss | standar |
dB |
3.6 | 7.0 | 10.2 | 13.3 | 16.5 | 20.0 |
| MAX(p/s) | 3.8/4.0 | 7.2/7.4 | 10.5/10.7 | 13.5/13.9 | 16.5/17.2 | 20.0/21.5 | ||
| PDL | dB | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 | ≤0.3 | |
| Lossuniformaity | dB | ≤0.6 | ≤0.8 | ≤1.0 | ≤1.4 | ≤1.6 | ≤1.9 | |
| Return loss@1550nm | dB | ≥55 | ≥55 | ≥55 | ≥55 | ≥55 | ≥55 | |
|
Wavelengthdependent loss |
dB | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | |
| Fiber length | m | 1.2(±0.1) or customer specified | ||||||
| Fiber length | Corning SMF-28eor customer specified | |||||||
| Fiber type | dB | ≤0.5 | ||||||
|
Temperature stability(-40 to +85) |
dB | ≤0.5 | ||||||
|
Operating/storage temperature |
℃ | -40 to +85 | ||||||
| Max optical power | mW | 300 | ||||||
