EU 200*40mm 7 Inch 9 Inch Mechanical Brake Shoes For Semi Trailers
EU Market Mechanical Brake Shoe Suit 7 Inch 9 Inch Mechanical Brake
Mechanical Brakes
Brakes absorb energy and convert it to heat. Thus, prime concerns in a brake are:
1. Generating a force capable of retarding a rotating shaft.
2. Dissipating or absorbing the heat generated in the process.
Mechanical brakes all act by generating frictional forces as two surfaces rub against each other. The stopping power or capacity of a brake depends largely on the surface area of frictional surfaces as well as on the actuation force applied. The friction and wear encountered by the working surfaces are severe. Thus, the durability of a brake or service life between maintenance depends heavily on the type of material used to line the shoe or pad.
Specifications
| Item | Part No. | QTY/BRK | Description |
| 0 | AZ00900000L | 1 | LH Complete Brake Assebmly(shown) |
| 0 | AZ00900000R | 1 | RH Complete Brake Assebmly |
| 1 | AZ00900100 | 1 | Backing Plate Assebmly |
| 2 | AZ00900401 | 2 | Adjusting shoe post |
| 3 | AZ00900403 | 1 | Adjusting bolt |
| 4 | AZ00901001 | 2 | Releasing post |
| 5 | AZ00900402 | 1 | Adjusting wedge |
| 6 | AZ00900200 | 1 | Brake shoe &lining kit |
| 7 | AZ00900901 | 1 | Adjusting spring |
| 8 | AZ00900903 | 1 | Retractor spring |
| 9 | AZ00900501 | 1 | Brake shoe expander |
| 10 | AZ00900902 | 1 | Hold down spring |
| *11 | AZ00900701 | 1 | brake cable Eyelet |
| *12 | AZ00900801 | 1 | Half shell cable cover |
FAQ
Q1: Are you trading company or manufacture?
A: We are factory,and welcomed to visit our factory.
Q2:Can I mix different models in one container?
A:Yes while quantity of each model reaches MOQ.
Q3:Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q4:How about your delivery time?
A: Generally, it will take about 35 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Our advantage
1. We have Researching and Development Department in Detroit,so we are also capable of developing products according drawing or samples to meet the special requirement of our customes.
2. We can supply 7 inch,10 inch,12 inch and 12.25 inch brakes for the moment.
3. All the parts for the brakes are produced by ourself,so we can supply our customer high quality products with resonable price.
4. We can also supply axle assemly.
