120V 220V HB-03 300Kg Pipe Welding Positioner 10mm-600mm
120V 220V Customized HB-03 300 Kg Welding Positioner Max Load 300 Kg Weight 10 Mm - 600 Mm In Diameter
300 kg welding positioner is mainly applied to under 300 kg weight, 10 mm - 600 mm in diameter of workpiece.High welding chuck, bracket, adjustable bracket, pneumatic tail cap etc accessaries are optional according to customer's workpiece.
The main technical parameters:
| Maximum carrying weight | 300 kg |
| Through-hole diameter of machine | 90-130mm |
| Rated eccentricity | / |
| Rotation speed | 0.2-2.5Rpm |
| Table turning angle | 0～90° |
| Rated voltage | 120V 220V Customized |
| Diameter of worktable | 500mm |
| Height of worktable | 650mm |
| Rotation way | By manual/electric |
| Rotation power | 240W |
| Suitable clip | KP-300/400/500 |
| Overall dimensions (L × W × H) | 590L×650W×650Hmm |
Welding positioners can be equipped with the chuck is 300, 400,500, welding chuck.
300 welding chuck clamping range is: 80 mm - 280 mm, with long claws can flat clamping 10 mm - 400 mm, 400 welding chuck clamping range is 120-380 - mm, with long claws after holding 10 mm - 500 mm, 500 welding chuck clamping range is 180 mm - 180 mm, special welding chuck maximum clamping 500 to 600 mm.
Operation:
1. Mounting foot switch
2. Power on
3. Setting forward and reverse rotation and welding speed:
Manually--Installation workpiece--Start welding
Automatic--Setting time relay--Press the linkage button(optional)--Installation workpiece--Start automatic welding
