3000kg 34kw Full servo Motor High Speed Disposable Paper Cup Forming Machine
3000kg 34kw Full Servo Motor High Speed Disposable Paper Cup Forming Machine
3000kg 34kw Full Servo Motor High Speed Disposable Paper Cup Forming Machine uses servo indexing mechanism, replaced the traditional paper cup machine which uses the geneva indexing mechanism. It's new in paper cup machine manufacture field. Servo indexing mechanism no need oil lubricant, no need maintenance, easy installation. It is more flexible for the machine self-adjustment while machine change the speed, even machine working in worse running conditions.. Full servo driven technology throughout the entire machine. Servo drives work independently to control each station with remarkable accuracy and work together to coordinate the synchronized motion. It replaced the market almost gear/ chain transmission and cam design paper cup machine. It provides flexibility, speed, affordable capital cost and low maintenance. Machine speed is 140-160 pcs/min.
♦Technical Parameters♦
|
Type |
PF-OC100 3000kg 34kw Full Servo Motor High Speed Disposable Paper Cup Forming Machine |
|
Cup size: |
4-16 oz (other customized size) |
|
Production capacity |
140-160 pcs/minutes |
|
Power source: |
380V 50HZ( or customized ) |
|
Suitable Material: |
170-380g/m2 (single or double-coated paper) |
|
Air source |
0.6 Mpa |
|
Total Power: |
34 KW |
|
Package size: |
2460*1620*1780mm |
|
Packaging of cup collection |
3000kg |
|
H.S code for customs: |
8441309000 |
♦Feature♦
1. PLC intelligent control, more accurate, easier operation and the labor is greatly reduced
2. Multiple cooling fans for heat dissipation ensuring that the machine keep suitable temperature when working.
3. Automatic oil lubrication, no need worker spraying oil manually which greatly saves labor.
4. Servo driver, making the speed very far
5. Cup collection, savingmore laber cost
♦Company Information♦
Zhengzhou Perfect Co., Ltd. specialize in producing paper cup machine, high cup machine, paper bowl machine, paper box machine, dining box machine and other paper packaging equipments. Our company integrates research and development, production, sales and maintenance, constantly introducing new and high technology, focusing on after-sales service.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in industry, food and other industries and are widely recognized and trusted by users and can meet continuously changing economic and social needs.
We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
♦FAQ♦
1.Q: Is it possible to produce paper cups of different sizes on the same paper cup making machine?
A: Yes, just need to change the mold
2.Q: Payment term?
A: T/T 30% as advance, the balance by T/T after production.
3.Q : Quality Guarantee?
A: One year warranty and lifelong technical service, the seller guarantee the machines are 100% new. The above clause is ONLY effective under the machine is being properly used, any artificial misuse or destroy prepensely is not within the limit of Quality Guarantee.
4.Q : Delivery time?
A: Within 35 days after receiving deposit
5.Q : Installation and Debugging of paper cup making machine?
A: we can send technician for installation and training at the cost of buyer (visa, round tickets, eating, accommodation in his country and salary 100 USD /day
