Purification Nucleic Acid Extraction System 1-32 Channels
Ease of Operation
Color touch screen with simple and clear graphical interface.
Safe and Reliable
Use of disposable extraction tube, UV sterilization lamp, high-efficiency filtration system to prevent cross-contamination and ensure biological safety.
High Efficiency and Flexibility
Compact, 32-channel throughput, fast extraction speed, high purified product rate.
Open and Customized
An open and customized platform, compatible for various extraction reagents in magnetic bead method.
Nucleic acid purification instrument-AiNA 32 Automatic Nucleic Acid Extractor
Product parameters:
| Dimension | 410mm×420mm×480mm |
| Weight | 25kg |
| Operation interface | Color touch screen |
| Handling volume | 20-1000μL |
| Throughput channel | 1-32 |
| Plate type | 96 deep-well plate |
| Oscillation mode | Multi-mode setting with adjustable frequency and amplitude |
| Temperature control | Metal bath wrapped heating |
| Lysis temperature | Room temperature ~ 100℃ |
| Washing temperature | Room temperature ~ 100℃ |
| Sterilization | UV sterilization lamp, high-efficiency filtration system |
| Program management | New establish, edit and delete |
| Compatible reagent | Compatible for various extraction reagents in magnetic bead method |
Product description
AiNA 32 is an accurate laboratory instrument for the extraction and purification of nucleic acids from human samples. Adopting magnetic bead separation technology, AiNA 32 can automatically complete the whole process including lysis, adsorption, cleaning, washing and recycling etc. It can handle up to 32 samples at the same time with ease of operation and high extraction efficiency, which make it widely used in scientific research, in vitro diagnostics, food safety, forensic and other fields.
Features:
Company profile
Aikang Group is a national high-tech enterprise specialized in R&D, production, sales and service of medical devices.
Aikang is always focusing on innovation and quality, constantly communicating with partners from Germany, Switzerland etc., and insisting on developing products under international standards with its own intellectual properties. Every year, over 10% of sales revenue is invested in R&D. By 2020, Aikang has achieved 187 patents applied and certificates of ISO, CE etc.
