1-32 Channels Automatic Nucleic Acid Extraction System
Principle:
After the sample is lysed by the lysis solution,the lysed nucleic acid will specifically adsorbed by the magnetic beads. Through the cooperation of the washing solutionⅠ,washing solutionⅡ,elution buffer and magnetic rod,various impurities that are not specifically bound to the magnetic beads are removed,and the magnetic beads adsorbing the nucleic acid are separated from the lysis solution. Finally, removing the magnetic beads,the nucleic acid molecules are dissolved in the elution buffer.
Auto Nucleic Acid Extraction&Purification system-AiNA 32
Product parameters:
| Dimension | 410mm×420mm×480mm |
| Weight | 25kg |
| Operation interface | Color touch screen |
| Handling volume | 20-1000μL |
| Throughput channel | 1-32 |
| Plate type | 96 deep-well plate |
| Oscillation mode | Multi-mode setting with adjustable frequency and amplitude |
| Temperature control | Metal bath wrapped heating |
| Lysis temperature | Room temperature ~ 100℃ |
| Washing temperature | Room temperature ~ 100℃ |
| Sterilization | UV sterilization lamp, high-efficiency filtration system |
| Program management | New establish, edit and delete |
| Compatible reagent | Compatible for various extraction reagents in magnetic bead method |
Product description
AiNA 32 is an accurate laboratory machine for the extraction and purification of nucleic acids from human samples. Adopting magnetic bead separation technology, AiNA 32 can automatically complete the whole procedure including lysis, adsorption, cleaning, washing and recycling etc. It can handle up to 32 samples at the same time with ease of operation and high extraction efficiency, which make it widely used in scientific research, in vitro diagnostics, food safety, forensic and other fields.
Features:
Ease of Operation
Color touch screen with simple and clear graphical interface.
Safe and Reliable
Use of disposable extraction tubes, UV sterilization lamp, high-efficiency filtration system to prevent cross-contamination and ensure the biological safety.
High Efficiency and Flexibility
Compact, 32-channel throughput, fast extraction speed, high purified product rate.
Open and Customized
An open and customized platform, compatible for various extraction reagents in magnetic bead method.
Company profile
Aikang Group is a national high-tech enterprise specialized in R&D, production, sales and service of medical devices.
Aikang is always focusing on innovation and quality, constantly communicating with partners from Germany, Switzerland etc., and insisting on developing products under international standards with its own intellectual properties. Every year, over 10% of sales revenue is invested in R&D. By 2020, Aikang has achieved 187 patents applied and certificates of ISO, CE etc.
