12 - 48VDC Industrial Ethernet Switch 8 Port 10/100/1000T + 6 Port 1000X SFP
Price:
$19.9-399
MOQ:
1pcs
Delivery Time:
7-10 working days
Brand:
E-link
Product Description
Industrial 8-Port 10/100/1000T + 6-Port 1000X SFP Ethernet Switch
Industrial Ethernet Switch Advantages:
- 8x10/100/1000Base-T + 6x1000Base-X SFP
- 10/100/1000Mbps RJ45 Port supports Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX
- Redundant Power Inputs
- IEEE 802.3az Energy Efficient Ethernet (EEE)
Technical Indexes
| Ethernet | |
| Packet Buffer Memory: | 2.75M bits |
| Processing Type: | Store-and-Forward |
| Max Packet Length: | 9K Bytes Jumbo Frame |
| Address Table Size: | 8K MAC Addresses |
| Connector: | 8 x RJ45 |
| Optical Port: | 6 x 1000Base-X SFP |
| Storage Temperature: | -40°C to 85°C (-40°F to 185°F) |
| MTBF | > 200,000 hrs |
| Input Power: | 12~48VDC, Redundant Power (6-pin Terminal Block) |
| Power Consumption: | 16W Max. |
Overview
LNK-IMC608G-SFP Series is 8-port 10/100/1000Base-T + 6-port 1000Base-X SFP hardened Ethernet switch.
Ordering Information
| Model | Description |
| LNK-IMC608G-SFP | Industrial 8-Port 10/100/1000T + 6-Port 1000X SFP Ethernet Switch |
| SFP Options | SFP option. Please select your SFP on our SFP Options Page |
| SFP module is to be purchased separately. | |
| Mounting Options | Default DIN-Rail Bracket installed |
| Power Options | DIN-Rail Power Supply. Open Wire for Terminal Block. |
| Power Supply is to be purchased separately. |
