Aluminum Industrial PoE Switch 8 Port 1000T 802.3at PoE + 4 Port 1G SFP + 2 Port 10G SFP+
Price:
$29.9-389
MOQ:
1pcs
Delivery Time:
7-10 working days
Brand:
E-link
Product Description
Industrial 8-Port 10/100/1000T 802.3at PoE + 4-Port 1G SFP + 2-Port 10G SFP+ Ethernet Switch
Industrial PoE Switch Advantages:
- 8x10/100/1000Base-T + 4x1000Base-X SFP + 2x 10GBase-SR/LR SFP+
- 10/100/1000Mbps RJ45 Port supports Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX
- IEEE802.3af/at compliant
Technical Indexes
| Connector: | 8 x RJ45 |
| Optical Port: |
4 x 1000Base-X SFP 2 x 10G Base-SR/LR SFP+ |
| Standard: | IEEE 802.3at Power over Ethernet Plus |
| IEEE 802.3af Power over Ethernet | |
| ort: | RJ45 |
| Power Pin Assignment | 4/5(+), 7/8(-) |
| PoE Budget: | Up to 240-watt PoE budget |
| Operating Temperature: | -40°C to 80°C (-40°F to 176°F) |
| MTBF | > 200,000 hrs |
| Input Power: | 48~57VDC, Redundant Power (6-pin Terminal Block) |
| Power Consumption: | 16W Max.(PoE in Use<240W) |
| PoE (Optional) | PoE Status |
| Fiber: | Gigabit SFP Port: F1~F4 |
| 10G SFP+ Port: G1, G2 | |
| Casing: | Aluminum Case |
Overview
LNK-IMC2X4S8GP Series is 8-port 10/100/1000Base-T 802.3at PoE + 4-port 1000Base-X SFP + 2-port 10G Base-SR/LR
SFP+ hardened Ethernet switch.
Ordering Information
| Model | Description |
| LNK-IMC2X4S8GP | Industrial 8-Port 10/100/1000T 802.3at PoE + 4-Port 1G SFP + 2-Port 10G SFP+ Ethernet Switch |
| SFP Options | SFP option. Please select your SFP on our SFP Options Page |
| SFP module is to be purchased separately. | |
| Mounting Options | Default DIN-Rail Bracket installed |
| Power Options | DIN-Rail Power Supply. Open Wire for Terminal Block. |
| Power Supply is to be purchased separately. |
