Industrial 8-Port 10/100/1000T + 4-Port 1000X SFP Ethernet Switch
Price:
$19.9-399
MOQ:
1pcs
Delivery Time:
5-12 working days
Brand:
E-link
Product Description
Industrial Ethernet Switch Advantages
► IP40 Aluminum Case
► Supports DIN-Rail installation
► 12-48V DC Power Input
► 8W Max Power Consumption
► Aluminum Case
Technical Indexes
| RS485 Serial Interface (Optional) | |
| Physical interface | Industrial standard 3-pin screw terminal |
| Data type | 1Ch RS485 Bi-Direction |
| RS-485 signals | Data +, Data-, GND |
| Serial port line distance (copper) | 1000 meters |
| Baud rate | 0 ~ 800kbps |
| Environmental | |
| Operating Temperature: | -40°C to 80°C (-40°F to 176°F) |
| Storage Temperature: | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity: | 5% to 95% non-condensing |
| MTBF | > 200,000 hrs |
Overview
LNK-IMC408G Series is the 8-port 10/100/1000Base-T + 4-port 1000Base-X SFP hardened Ethernet switch. The Switch has
8 Gigabit Ethernet ports and 4 SFP fiber ports. TP (RJ45) supports 10/100/1000Base-T(X), Full/Half duplex mode, and auto
MDI/MDI-X connection; 1000Base-X supports 1 or 2 core Single-mode or Multi-mode fiber.
Ordering Information
| Model | Description |
| LNK-IMC408G | Industrial 8-Port 10/100/1000T + 4-Port 1000X SFP Ethernet Switch |
| SFP Options | ► SFP option. Please select your SFP on our SFP Options Page |
| ► SFP module is to be purchased separately. | |
| Mounting Options | ► Default DIN-Rail Bracket installed |
| Power Options | ► DIN-Rail Power Supply. Open Wire for Terminal Block. |
| ► Power Supply is to be purchased separately. |
