Mini Industrial 2port 10/100/1000Base-T + 2port 100/1000Base-X SFP Ethernet Switch
Price:
$19.9-399
MOQ:
1pcs
Delivery Time:
5-12 working days
Brand:
E-link
Product Description
Mini Industrial Ethernet Switch Advantages
► 2-port 10/100/1000BASE-T RJ45 with auto MDI / MDI-X function
► 2 SFP Port, 100Base-FX or 1000Base-X dual mode (auto detection)
► Supports Link Fault Pass Through
► Supports Full/Half-duplex, Auto-negotiation
► 9K Bytes Jumbo Frame
Technical Indexes
| Interface | |
| Connector: | 2 x RJ45 |
| Optical Port: | 2 x SFP 1000Base-X or 100Base-FX (auto detection) |
| Electrical and Mechanical | |
| Input Power: | 12~48VDC, 4-pin terminal block |
| Power Consumption: | 5W Max. |
Overview
LNK-IMC202G-SFP Series is a DIN Rail type Ethernet Switch that supports external SFP Modules and meets EN55022 standard.
It is a hardened grade product whose operating temperature range is -40°C to +75°C.
Ordering Information
| Model | Description |
| LNK-IMC202G-SFP | Hardened 2-Port 10/1001000BASE-TX to 2x100/1000BASE-X SFP Ethernet Switch |
| SFP Options | ► SFP option. Please select your SFP on our SFP Options Page (Industrial SFP). |
| ► SFP module is to be purchased separately. | |
| Mounting Options | ► Default DIN-Rail Bracket installed, Wall Mount Bracket is included. |
| Power Options | ► 24W/1A 24VDC Power Supply. Open Wire for Terminal Block |
| ► Power Supply is to be purchased separately. |
