19 Inch 1U 8 Port Metered PDU Build-in Power meter with OLED display

Name: 19 Inch 1U 8 Port Metered PDU Build-in Power meter with OLED display
Brand: E-link China Technology Co.,LTD

Price Negotiable

Price: $25-369

MOQ: 1 pair

Delivery Time: 3-5 working days

Brand: E-link

Product Description

19 Inch 1U 8 Port Metered PDU

Model: LNK- IPDU_7GB10_ZK_GB

Overview

E-link's Electric Basic Rack Power Distribution Unit (PDU) is a high-performance 19 Inch 1U 8

Port Metered PDU, specifically engineered to provide centralized power distribution and real-time

energy monitoring for devices installed in 19’’ standard racks—catering to data centers, server rooms,

and network wiring closets where precise power management and equipment efficiency tracking are

critical. As a 19 Inch 1U 8 Port Metered PDU, it combines space-saving 1U rack-mount design with

accurate 电能计量(power metering)功能, enabling users to monitor key power parameters while

optimizing rack space utilization.

This PDU is equipped with 8 power outlets, offering sufficient connectivity to power multiple devices

simultaneously—such as servers, network switches, storage arrays, or monitoring equipment—while

its integrated metering function provides real-time data on voltage, current, power consumption, and

energy usage. This metering capability allows IT and facility managers to track power distribution

efficiency, identify energy-wasting devices, and plan for capacity expansion, which is essential for

reducing operational costs and improving the sustainability of data center or server room infrastructure.

Designed for universal compatibility, the 19 Inch 1U 8 Port Metered PDU supports 10/16A current and a

wide voltage range of 100–240V, enabling seamless adaptation to different regional power grids. It can

deliver stable single-phase AC power to multiple loads from various input sources, including utility outlets,

generators, or UPS (Uninterruptible Power Supply) systems—ensuring consistent power supply even in

scenarios with fluctuating input power.

The PDU features a reversible all-metal housing, which enhances structural durability to withstand the

wear and tear of high-density rack environments, while also supporting versatile mounting options. It can

be installed as a 1U horizontal unit or 0U vertical unit in EIA-standard 19-inch racks (adapting to different

rack space requirements), mounted under a counter for desktop equipment, or fixed on a wall or workbench

for flexible deployment in non-rack environments—catering to diverse site layouts in data centers, server

rooms, or network wiring closets.

With its reliable power distribution, accurate metering function, wide voltage compatibility, and flexible

mounting design, the 19 Inch 1U 8 Port Metered PDU ensures consistent power supply to critical

equipment while enabling data-driven power management. It is an ideal solution for enterprise data

centers, small-to-medium server rooms, network operation centers (NOCs), and industrial control

cabinets—effectively improving equipment reliability, reducing energy waste, and simplifying power

infrastructure maintenance.

Features

► 85–265V AC input, 8 total outlets

► Max 16A / 2800W Output

► Support 19 inch Rack-mount

► Different plug types available

► Build-in Power meter with OLED display

► Gen 3 10KA Surge Protection module

► L and N Double-break Switch

► UL94V-0 Grade Flame Resistant Material

► Four-layer Piano Paint T6 Hardened Aluminum Profile

► Complies with the requirements of IEC60297 standards

► EMI.RFI Protection

Technical Indexes

OUTPUT
PDU type	19 inch rack mount Surge Protection PDU
Voltage output	85V~265VAC
Working Frequency	50/60Hz
Output Capacity Details	3.68kW (230V), 1.76kW(110V)
Outlets type	US, EU, UK, IEC available
Overload Protection	Yes
Voltage Measurement	Range: 0~300V
Voltage Measurement	Display Digits: 0.01V
Current Measurement	Input: Transformer
	Range: 0~30mA
	Display Digits: 0.01A
Power Measurement	Accuracy: Grade 1
Power Measurement	Display Digits: 0.01kW
Electricity Measurement	Accuracy: Grade 1
Electricity Measurement	Display Digits: 0.01kW
Display	OLED Screen, Blue text on black / White text on black
INPUT
PDU Input Voltage	85-265V AC
Maximum Input Amps	10/16A
PDU Plug Type	US, EU, UK, IEC 3 Pin available
Phase line	Single Phase
Input Cord Details	1.8m / 5.9ft
PHYSICAL
Form Factors Supported	1U rackmount, 0U vertical rackmount, wall-mount, and under-counter installation
Material of Construction	Aluminum T6 Hardened Profile with Four-layer Piano Paint
Minimum Required Rack Depth	59mm / 2.3in
Unit Weight	1.05kg / 2.31 lbs
Photosensitive Detection	Normally used for automatic lighting with extended functions
ENVIRONMENTAL
Operating Temperature	-10 to 50°C
Storage Temperature	-30 to 60°C
Relative Humidity	5 to 95% non-condensing
Operating Elevation	0-4000m
Warranty Period	5-year limited warranty

ordering information

Model Number	Installation	specification		Input Cable	Input		Output	Output Interface	accessories	Remark
Model Number	Installation	specification		Input Cable	Control			Output Interface	accessories	Remark
LNK- IPDU_7GB10_ZK_GB	Horizontal	19’’	1U	1.8m	85-265V AC	GB2015, Max=13A, 8CH Control output		GB1002(10A/250V)	Smart Meter	Input Plug Customizable
LNK- IPDU_7IEC13K_ZK_IEC14	Horizontal	19’’	1U	1.8m	85-265V AC	IEC320-C1 (Cable anti falling), Max=13A, 7CH Control output		IEC60320 C13	Smart Meter	Input Plug Customizable
LNK- IPDU_7WY10_ZK_GB	Horizontal	19’’	1U	1.8m	85-265V AC	Universal plug Max=16A, 7CH Control output		GB 2099.3(16A/250V)	Smart Meter	Input Plug Customizable
LNK- IPDU_8UL_ ZK_UL	Horizontal	19’’	1U	1.8m	85-265V AC	Universal plug Max=16A, 8CH Control output		NEMA5-15R(16A/250V)	Smart Meter	Input Plug Customizable
Note: More Input and output interface type available, please contact us for more details.

Application
