Stainless Steel Psa Oxygen Concentrator For Industrial Use
Price:
usd2000~80000 per set
MOQ:
1set
Delivery Time:
3~5weeks
Brand:
cape golden
Product Description
220V Psa Carbon Steel Industrial Oxygen Generator / Concentrator
Oxygen Generators Use Psa Technology To Produce Oxygen With A Sieve Material Called Zeolite. A Compressed Air Stream Is Passed Through A Pressure Vessel Filled With Zeolite Sieve. The Porosity Structure Of Zeolite Allows The Material To Capture And Absorb The Larger Nitrogen Molecules As The Compressed Air Flows Through, Leaving A Stream Of Oxygen To Flow Out The Opposite End Of The Pressure Vessel.
| name | 220V Psa Carbon Steel Industrial Oxygen Generator / Concentrator |
| keyword | psa industrial oxygen concentrator |
| Voltage | 220V/380/420/440V or as customized |
| Type | Skid mounted or Containerized |
| Purity | 90-99% optional |
| Capacity | 1-120 Nm3/h per unit set |
| Application | Hospital and industry |
| Main components | Air Compressor , Refrigerated Dryer, Air filters ,Oxygen generator , Oxygen booster, filling ramp, etc. |
| Technology | Pressure Swing Adsorbtion (PSA) |
| Working Pressure | 4-200 bar |
| Power Consumption | 0.1kw |
| Material | Carbon Steel/ Stainless steel |
| Operation type | Automated |
Slection Table:
| CAPE GOLDEN® PSA Oxygen generator for refilling cylinders | |||||
| Model | Qty of cylinders (pieces/day--24hours) Cyinders: 40L/150bar (storage 6000L gas) |
Purity(%) (90%,93%, 95%, 99% optional) |
Flow Rate ( Nm3/h) |
Flow Rate ( Liter/h) |
Flow Rate ( Liter/min) |
| CAOG-3 | 12 | 93~99 | 3 | 3,000 | 50 |
| CAOG-5 | 20 | 93~99 | 5 | 5,000 | 83 |
| CAOG-10 | 40 | 93~99 | 10 | 10,000 | 167 |
| CAOG-15 | 60 | 93~99 | 15 | 15,000 | 250 |
| CAOG-20 | 80 | 93~99 | 20 | 20,000 | 333 |
| CAOG-25 | 100 | 93~99 | 25 | 25,000 | 417 |
| CAOG-30 | 120 | 93~99 | 30 | 30,000 | 500 |
| CAOG-35 | 145 | 93~99 | 35 | 35,000 | 583 |
| CAOG-40 | 160 | 93~99 | 40 | 40,000 | 667 |
| CAOG-45 | 180 | 93~99 | 45 | 45,000 | 750 |
| CAOG-50 | 200 | 93~99 | 50 | 50,000 | 833 |
| CAOG-60 | 240 | 93~95 | 60 | 60,000 | 1,000 |
| CAOG-70 | 280 | 93~95 | 70 | 70,000 | 1,167 |
| CAOG-80 | 320 | 93~95 | 80 | 80,000 | 1,333 |
| CAOG-90 | 360 | 93~95 | 90 | 90,000 | 1,500 |
| CAOG-100 | 400 | 93~95 | 100 | 100,000 | 1,667 |
| CAOG-120 | 480 | 93~95 | 120 | 120,000 | 2,000 |
| CAOG-150 | 600 | 93~95 | 150 | 150,000 | 2,500 |
| Remark: Cylinders capacity is 6m3 | |||||
| For more details , pls feel free to contract with us. | |||||
