MC901 Nylon Backing Board Square Strip Long Strip Nylon Board General Engineering Plastics
MC901 Nylon Backing Board Square Strip Long Strip Nylon Board General Engineering Plastics
Nylon, the Chinese name of polyamide, and the English name of Polyamide (PA), is the general term for thermoplastic resins containing repeating amide groups—NHCO—on the main chain of the molecule. The name is determined by the specific number of carbon atoms of the synthesized monomer. It was invented by the famous chemist Carlosius of DuPont, the largest chemical industry company in the United States, and his scientific research team.
Density³
Conductivity (σ)10-/m
Thermal conductivity·K)
Nylon board has high mechanical strength, stiffness, hardness, toughness, good aging resistance, good mechanical damping ability, good sliding properties, excellent wear resistance, good machining performance, and no creep when used for precise and effective control. , Good anti-wear performance and good dimensional stability.
| Property | Item No. | Unit | MC Nylon (Natural) | Oil Nylon+Carbon (Black) | Oil Nylon (Green) | MC901 (Blue) | MC Nylon+MSO2 (Light black) |
| 1 | Density | g/cm3 | 1.15 | 1.15 | 1.135 | 1.15 | 1.16 |
| 2 | Water absorption (23℃ in air) | ％ | 1.8-2.0 | 1.8-2.0 | 2 | 2.3 | 2.4 |
| 3 | Tensile strength | MPa | 89 | 75.3 | 70 | 81 | 78 |
| 4 | Tensile strain at break | ％ | 29 | 22.7 | 25 | 35 | 25 |
| 5 | Compressive stress(at 2%nominal strain) | MPa | 51 | 51 | 43 | 47 | 49 |
| 6 | Charpy impact strength (unnotched) | KJ/m2 | No break | No break | ≥50 | No BK | No break |
| 7 | Charpy impact strength (notched) | KJ/m2 | ≥5.7 | ≥6.4 | 4 | 3.5 | 3.5 |
| 8 | Tensile modulus of elasticity | MPa | 3190 | 3130 | 3000 | 3200 | 3300 |
| 9 | Ball indentation hardness | N2 | 164 | 150 | 145 | 160 | 160 |
| 10 | Rockwell hardness | - | M88 | M87 | M82 | M85 | M84 |
