Pa66 Plastic Nylon Board Sheets Zero Cut MC901
Nylon plastic board MC901 nylon material wear-resistant pa66 nylon board processing zero cut General Engineering Plasti
Nylon 66+MOS2 (gray black): This nylon is filled with molybdenum disulfide. Compared with nylon 66, its rigidity, hardness and dimensional stability are improved, but the impact strength is reduced. The crystal grain formation effect of the crystalline structure improves the crystalline structure, and improves the material load-bearing and wear resistance performance. Casting nylon board is also called MC nylon: English name Monomercastingnylon, Chinese called monomer casting nylon. "Using plastic to replace steel with excellent performance" is extremely versatile. It has many unique properties such as light weight, high strength, self-lubricating, wear-resisting, anti-corrosion, insulation and so on. It is a widely used engineering plastic, which can be found in almost all industrial fields
| Property | Item No. | Unit | MC Nylon (Natural) | Oil Nylon+Carbon (Black) | Oil Nylon (Green) | MC901 (Blue) | MC Nylon+MSO2 (Light black) |
| 1 | Density | g/cm3 |
1.15 |
1.15 | 1.135 | 1.15 | 1.16 |
| 2 | Water absorption (23℃ in air) | ％ | 1.8-2.0 | 1.8-2.0 | 2 | 2.3 | 2.4 |
| 3 | Tensile strength | MPa | 89 | 75.3 | 70 | 81 | 78 |
| 4 | Tensile strain at break | ％ | 29 | 22.7 | 25 | 35 | 25 |
| 5 | Tensile strain at break | ％ | 29 | 22.7 | 25 | 35 | 25 |
| 6 | Charpy impact strength (unnotched) | KJ/m2 | No break | No break | ≥50 | No BK | No break |
| 7 | Charpy impact strength (notched) | KJ/m2 | ≥5.7 | ≥6.4 | 4 | 3.5 | 3.5 |
| 8 | Tensile modulus of elasticity | MPa | 3190 | 3130 | 3000 | 3200 | 3300 |
| 9 | Ball indentation hardness | N2 | 164 | 150 | 145 | 160 | 160 |
| 10 | Rockwell hardness | - | M88 | M87 | M82 | M85 | M84 |
