Flanschlager Ceramic Mini Ball Bearing 684 ZZ For Window Roller
Price:
USD0.03-USD0.04
MOQ:
10000PCS
Delivery Time:
Negotiable
Brand:
no brand
Product Description
Micro Flanschlager Deep Groove Ball Bearing 684 Zz For Medical Machinery
Deep groove ball bearings are widely used in gearboxes.instruments.motors. household appliances.
internal combustion engines.transportation vehicles. agricultural machinery.construction machinery.
construction machinery. roller roller skates. yo-yo. etc.
| YPE | BORE | outer diameter | width | basic load ratings | limiting speed | weight | ||
| dynamic | static | |||||||
| d(mm) | D(mm) | b(mm) | Cr(kgf) | Cor(kgf) | Grease(r/min) | Oil(r/min) | (kg/pc) | |
| 681 | 1 | 3 | 1 | 8.00 | 2.50 | 85000 | 100000 | 0.001 |
| 682 | 2 | 5 | 2.3 | 17.00 | 5.00 | 85000 | 100000 | 0.001 |
| 683 | 3 | 7 | 3 | 40.00 | 13.00 | 63000 | 75000 | 0.001 |
| 684 | 4 | 9 | 4 | 65.00 | 23.00 | 53000 | 63000 | 0.001 |
| 684 | 4 | 9 | 2.5 | 65.00 | 23.00 | 53000 | 63000 | 0.001 |
| 685 | 5 | 11 | 3 | 73.00 | 28.00 | 45000 | 53000 | 0.001 |
| 685 | 5 | 11 | 4 | 73.00 | 28.00 | 45000 | 53000 | 0.001 |
| 685 | 5 | 11 | 5 | 73.00 | 28.00 | 45000 | 53000 | 0.001 |
| 686 | 6 | 13 | 3.5 | 110.00 | 29.00 | 40000 | 50000 | 0.002 |
| 686 | 6 | 13 | 5 | 110.00 | 45.00 | 40000 | 50000 | 0.002 |
| 686 | 6 | 13 | 4 | 110.00 | 45.00 | 40000 | 50000 | 0.002 |
| 687 | 7 | 14 | 3.5 | 120.00 | 45.00 | 40000 | 50000 | 0.002 |
| 687 | 7 | 14 | 5 | 120.00 | 52.00 | 40000 | 50000 | 0.002 |
| 688 | 8 | 16 | 4 | 164.00 | 73.00 | 36000 | 43000 | 0.003 |
| 688 | 8 | 16 | 5 | 164.00 | 73.00 | 36000 | 43000 | 0.003 |
| 689 | 9 | 17 | 4 | 136.00 | 68.00 | 36000 | 43000 | 0.003 |
| 689 | 9 | 17 | 5 | 136.00 | 68.00 | 36000 | 43000 | 0.003 |
